A-12742-50023
CPU Board
o
o
o
N N
lnO'l
a a
DO
D D
DO
..
gg
.D '-
g g
l\)
DD ~
~~
.-
aD
DO
g g
o
"'-l
m
e....
I\)
(5
o
c
J212
.1206
1000.00001
10•.
00000001
8
1 9
1
\or-"--~
J205
J207
J209
~OJlOoooooooollo.-ooooooollooo.oooool
12
19
19
1
J201, 26-pin Ribbon Cable,
data, To/from J602
J202, 34-pin Ribbon Cable,
data, To/from J903; PI; J60l
J203-Not Used
J204, 26-pin Ribbon Cable, data To/from 8-Driver Board Jl
J205·1 Orange-Brown, ded. sw. row 1, to Coin Door Srd JI-14
J205·2 Orange-Red, ded. sw. row 2, to Coin Door Srd JI-13
J205 • 3 Orange-Black, ded. sw. row 3,
10
Coin Door Srd JI-12
J205·4 Orange-YellOW, ded. sw. row 4, to Coin Door Jl-17
J205 - 5 N/C
J205 - 6 Orange-Green, ded. sw. row 5, to Coin Door Brd
J
1-11
J205·7 Orange-Slue, ded. sw. row 6, to Coin Door Brd Jl-l0
J205 - 8 Orange-Violet, ded. sw. row 7, to Coin Door Brd JI-9
J205 - 9 Orange-Gray, ded. sw. row 8, to Coin Door Brd JI-8
J205 - 10 Slack, ground, to Coin Door Brd Jl-15
J205 - 11 N/C
J205 -12 Orange-White, sw. enable, to Coin Door Srd JI-18
J206-1 N/C
J206-2 N/C
J206-3 N/C
J206-4 N/C
J206-5 N/C
J206-6 N/C
J206-7 N/C
J206-8 N/C
J206-9 N/C
J207-1 Green-Brown, sw. col. 1, to playfield switches
J207·2 Green-Red, sw. col. 2, to playfield/cabinet switches
J207-3 Green-Orange, sw. col. 3, to playfield switches
J207-4 Green-Yellow, sw. col. 4, to playfield switches
J207·5 Green-Slack, sw. col. 5, to playfield switches
J207-6 Green-Blue, sw. col. 6, to play field switches
J207·7 Green-Violet, sw. col.
7,
to playtield switches
J207-8
N/C
J207-9 Green-Gray,
SW.
col. 8, to playfield switches
J208-1 N/C
J208-2
N/C
J208-3
N/C
J208-4
N/C
J208-5
N/C
J208-6 N/C
J208-7 N/C
J208-8
N/C
J208-9
N/C
J209·1 White-Brown, sw. row 1, to playfield switches
J209-2 White-Red,
SW.
row 2, to playfield switches
J209-3 White-Orange,
s«.
row
3,
to playfield switches
J209-4 White-Yellow, sw. row 4, to playfield switches
J209-S White-Green,
SW,
row 5, to playfield switches
J209·6
N/C
J209-7 White-Blue,
e«.
row 6, to playfield switches
J209-8 White-Violet, sw. row 7, to playfield switches
J209-9 White-Gray, sw. row
8,
to playfield switches
J210-1 Black, ground, from Power Driver Brd JI14-5,7
J210-2
N/C
J210-3 Slack, ground, from Power Driver Srd Jl14-5,7
J210-4 Gray, +5V, trom Power Driver Brd J114-3,4
J210-S Gray, +5V, from Power Driver Brd
J
114-3,4
J210-6 Gray-Green, + 12V, from Power Driver Srd J 114-1 ,2
J210-7 Gray-Green,
+
l2V, from Power Driver Brd Jl14-1 ,2
J211, 34-pin Ribbon Cable,
data, Tolfrom Jl13
J21~-1 Green-Brown, sw. col. 1, to Coin Door Srd Jl-l
J212-2 Green-Red, sw. col. 2, to Coin Door JI-7
J212·3
N/C
J212-4 White-Brown, sw, row 1, to Coin Door Srd JI-6
J212-5
N/C
J212-6 White-Red, sw. row 2, to Coin Door Brd Jl-5
J212·7 White-Orange, sw. row 3, Coin Door Srd Jl-4
J212·8 White-Yellow, sw, row 4, to Coin Door Srd Jl-3
.siilil iilrn
THE nEXT 6ERERilTRIIIR 3-Z9
