A-15542
Motor EMI PCB Assembly
(for left and right gun assemblies)
-
rJOlN
lL£J-'
N
L1
L2
I
Dl
lN4004
lA
Left EMI Board
J1-1 Black-Brown, ground from Power Driver Board J12S-1
J1-2
NlC
J1-3 Gray-Yellow, +12V from Power Driver Board J118-2
J2-1 Red, to left gun motor
J2-2 Black, to left gun motor
Right EMI Board
J1-1 Black-Red, ground from Power Driver Board J126-2
J1-2
NlC
J1-3 Gray-Yellow, +12V from Power Driver Board J118-2
J2-1 Red, to right gun motor
J2-2 Black, to right gun motor
