Proximity Sensor II PCB Assembly
J2joo1
1
2
W1
2
U1
R1
TDA0161
9.09Kn
I
C4
4
1mfd
J1
-
-
B
-
+12V
2
6
Row
4
Column
3
Left Proximity Sensor II
J1-1 Black, ground from Power Driver Board J118-3
J1-2 Gray-Yellow, +12V from Power Driver Board J118-2
J1-3 Green-Brown, sw. col. 1 from CPU J207-1
J1-4 White-Blue, sw. row 6 from CPU J209-7
Right Proximity Sensor II
J1-1 Black, ground from J118-3
J1-2 Gray-Yellow, +12V from Power Driver Board J118-2
J1-3 Green-Brown, sw. col. 1 from CPU J207-1
J1-4 White-Violet, sw. row 7 from CPU J209-8
J2-1 Red, to left Eddy Sensor
J2-2 Black, to left Eddy Sensor
J2-1 Red, to rilJht Eddy Sensor
J2-2 Black, to right Eddy Sensor
