I. INSTALLATION
Assemble the game as follows:
Bolt legs to cabinet. Bolt back box to cabinet. Use flat washers under bolt heads. Gently feed
cable connectors and ground braid through cable port in back box. Screw ground braid to
braid in back box. Carefully and fully insert connectors on printed circuit ass,emblies.
On all games there are certain items that should be checked after shipment. These are visual
inspections which may avoid time consuming service work later. Minor troubles caused by
abusive handling in shipment are unavoidable. Cable connectors may be loosened, switches
(especially tilt switches) may go out of adjustment. Plumb bob tilt switch should always be
adjusted after game is set on location and leg levelers are adjusted.
Visual inspections before plugging in line cord:
1. Check that all cable connectors are completely seated on printed circuit assemblies.
2. Check that cables are clear of all moving parts.
3. Check for any wires that may have become disconnected.
4. Check switches for loose solder or other foreign material that may have come loose in
shipment and could cause shorting of contacts.
5. Check wires on coils for proper soldering. Cold solder connections may not show up in
factory inspection, but vibration in shipment may break contact.
6. Check that fuses are firmly seated and making good contact.
7. Check the transformer for any foreign material shorting across wiring lugs.
8. Check wiring of transformer to correspond to location voltage. See.figure 1.
Check adjustment of the three (normally open) tilt switches:
1. Panel tilt on bottom of playfield panel.
2. Plumb bob tilt on left side of cabinet near front door.
3. Ball tilt above plumb bob tilt. Insert the smaller ball (15/16/1dia.) into the ball tilt assembly,
and adjust the bracket so the ball will roll free to contact the switch blade, if front of cabinet is
raised.
TRANSFORMER CONNECTION INSTRUCTIONS
REFER TO POWER SUPPLY SCHEMATIC
IN GAME MANUAL FOR TABLE "A"
i
!
115 VAC, 2-8,3-6,7-10
120 VAC, 2-8, 4-6, 7-11
220 VAC 4-8 7-9
240 VAC, 4-8, 7-11
1
1.
PART OF POWER-TRANSFORMER MODULE A2, LOCATED IN LOWER CABINET
