AS~2518·54 RECTIFIER BOARD ASSEMBLY
(Part of) A2:
POWER TRANSFORMER MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
0
A2
AS-2877-9
Power Transformer Module,
Complete
P/OA2
AS-2518-54
Rectifier Board Assembly,
Complete
3
R1
E-00104-0092
Resistor, 10%, 600 Ohm, 10W
4
R2
E-00104-0091
Resistor, 25 Ohm, 5W
5
R3
E-00105-0226
Resistor, 5%, 1OOKOhm,
V4
W
7
VR1
E-00623
Varistor
8
CR5, CR6, CR7, CR8
E-00587 -0022 3A Diode
9
CR1, CR2, CR3, CR4
E-00587-0015
Diode (IN4004)
10
11
Usedwith BR1-2
P-1973-480
Spacer
12
BR1, BR2
E-00602-0007
Bridge Rectifier
15
F2
E-00133-0028
Fuse, 3,4A,250V, 3AG
16
F3
E-00133-0004
Fuse, 4A, 32V, 3AG
17
F4
NOTE
1
E-00133-0005 / Fuse 5A, 32V, SAG
18
F1,F5
E-00133-0027
Fuse, 20A, 32V, 3AG
19
20
J1
E-806-9
9 CKT SocketHeader
21
TP1, 2, 3, 4, 5
P-05399
Test Clip
22
J2,J6
E-805-6
6 CKT Pin Header
23
J4, J5
E-805-9
9 CKT Pin Header
24
J3
E-805-12
12 CKT Pin Header
25
F2,3,4
E-00148-0021
Fuse Clips
26
F1,5
E-00148-0022
Fuse Clips (Low Resistance)
NOTE 1-AII
games with 4 or more flippers use7A
