A4: MPU MODULE
COMPONENT PARTS LIST
REFERENCE
BAllY
ITEM
DESIGNATION
PART
#
DESCRIPTION
1
A4(see note 1)
1
AS~2962-33
MPU Module Complete.
r
2
A4 (see note 2)
AS-2518-35
MPU Module less Program
t
Memory, U1-6 incl.
!
3-32
See Schematic
Resistors, See schematic for value
33
C14, C15
E-00586-0067
Capacitor, 470 PFD, 1kv
.(
34
C18
E-00586-0088
Capacitor, .05 MFD, 16V
35
C16
E-00586-0081
Capacitor,.1 MFD, 100V
36
C4,C5
E-00586-0073
Capacitor, 4.5 MFD, 25V
37
C3, C6-C13, C17, C81
E-00586-0085
Capacitor, .01 MFD, 25V
38
C79, C41-C67
E-00586-0083
Capacitor, 470 PFD, 50V
39
C19-C31, C78, C33-C40 E-00586-0082
Capacitor, 390 PFD, 50V
40
C1, C2, C68-C77
E-00586-0084
Capacitor, 820 PFD, 50V
41
C32
E-00586-0077
Capacitor, 3000 PF, 1kv
~
43
05
E-00585-0023
Transistor PNP (MPS-3702)
44
01,02
E-00585-0031
Transistor (2N3904)
47
CR44
E-00587-0006
Diode (lN4004)
(
48
CR1-CR7, CR11-CR43,
E-005B7-0014
Diode (lN4148)
CR45-CR49
Gf'"
49
CR8
E-00679
LED (Green)
50
VR1
E-00598-0008
Diode Zener (8.2V, IN9598)
52
L1,L2
E-00604-0003
Inductor, 22 Micro Hy.
53
U12
E-00620-0004
Timer (555)
54
U19
E-00620-0005
Quad 21nput (4011)
(
55
U9
E-00620-0028
MPU I.C. (6800)
\
56
U10, U11
E-00620-0029
PIA I.C. (6820)
57
U7
E-00620-0030
RAM I.C. (6810)
{
59
U20
E-00620-0032
HEX Buffer I.C. (14502B)
60
U14,U18
E-00620-0033
HEX Inverter (4049B)
,1l
61
U15
E-00620-0034
Quad Memory Drive (MC3459L)
62
U16
E-00620-0035
Dual Monostable (9602)
64
U17
E-00620-0041
Ouad 21nputs (74LOON)
65
U8
E-00620-0042
RAM (C MOS, P5101L-3)
68
BT1, BT2, BT3
E-00628-0003
Battery
70
S33
E-00658-0001
Push Button Switch
I
71
S1-S8, S9-S16, S17-S24,
E-00677
DIPSwitch
S25-S32
'
~
73
E:00712
24 Pin Socket
74
E-00712-0001
40 Pin Socket
r
75
E-00712-0003
22 Pin Socket
\
77
J2
E-00715
15 Pin Wafer Connector
78
J1
E-00715-0004
28 Pin Wafer Connector
(
79
J3, J5
E-00715-0017
16 Pin Wafer Connector
80
J4
E-00715-0018
19 Pin Wafer Connector
81
J5
E-00715-0024
17 Pin Wafer Connector
f
NOTE 1:
_
d
When ordering, fill in dash number. Forexample, AS-2962-0: LOST WORLD, AS-2962-2: SIX MILLION DOLLAR MAN, AS-2962-3:
,
PLAYBOY, AS-2962-4: VOLTAN, AS-2962-5: SUPERSONIC, AS-2~2-6:
STAR TREK, AS-2962-7: KISS, AS 2962-8: PARAGON,
AS-2962-9: GROUND SHAKER, AS-2962-10: HARLEM GLOBETERS, AS-2962-12: DOLLY PARTON, AS-2962-13: SILVERBALL
MANIA, AS-2962-18: MYSTIC, AS-2962-20: HOTDOGGIN, AS-2962-22: SKATE BALL, AS-2963-23: FRONTIER, AS-2962-21:
XENON, AS-2962-24: FLASK GORDON, AS-2962-26: EIGHT BALL DELUXE, AS-2962-25: FIREBALL II, AS-2962-28: FATHOM,
AS-2962-29: MEDUSA, AS-2962-30: CENTAUR AS-2962-31 ELEKTRA .. AS-2962-32 VECTOR. AS-2962-33: SPECTRUM .
t
\
NOTE 2: Order replacement memory chips Ul-U6, specifying game, socket and part number stamped on chip.
\
'
