A4: MPUMODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
1
A4 (see note 1)
AS-2962-17
MPU Module Complete.
Space Invaders
2
A4 (see note 2)
AS-2518-35
MPU Module.less Program
Memory, U1-6 incl.
3-32
See Schematic
Resistors, See schematic for value
33
C14, C15
E-00586·0067
Capacitor, 470 PFD, 1kv
34
C18
E-00586-0088
Capacitor, .05 MFD, 16V
I&I~
35
C16
E-00586-0081
Capacitor,.1 MFO, 100V
36
C4,C5
E-00586-00 73 Capacitor, 4.5 MFD, 25V
37
C3, C6-C13, C17, C81
E-00586-0085
Capacitor, .01 MFD, 25V
.1
38
C79, C41-C67
E-00586-0083
Capacitor, 470 PFD, 50V
39
C 19-C31 , C78, C33-C40
E-00586-0082
Capacitor, 390 PFD, 50V
40
C1, C2, C6S-C77
E-00586-0084
Capacitor, S20 PFD, 50V
41
C32
E-00586-0077
Capacitor, 3000 PF, 1kv
43
05
E-00585-0023
Transistor PNP (MPS-3702)
44
01,02
E-00585-0031
Transistor (2N3904)
47
CR44
E-00587-0006
Diode (IN4004)
48
CR1-CR7, CR11-CR43,
E-00587-0014
Diode (IN4148)
CR45-CR49
49
CR8
E-00679
LED (Green)
50
VR1
E-00598-0008
Diode Zener (8.2V, IN9598)
52
L1,L2
E-00604-0003
Inductor, 22 Micro Hy.
53
U12
E-00620-0004
Timer (555)
.:
54
U19
E-00620-0005
Quad 21nput (4011)
55
U9
E-00620-0028
MPU I.C. (6800)
I
56
U10, U11
E-00620-0029
PIA 1.C. (6820)
57
U7
E-00620-0030
RAM I.C. (6810)
~
59
U20
E·Q0620-0032
HEX Buffer I.C. (14502B)
,
60
U14,U18
E-00620-0033
HEX Inverter (4049B)
•
61
U15
E-00620-0034
Quad Memory Drive (MC3459L)
62
U16
E-00620-0035
Dual Monostable (9602)
64
U17
E-00620-0041
Ouad 21nputs (74LOON)
65
U8
E-00620-0042
RAM (C MOS, P5101L-3)
68
8T1, BT2, BT3
E-00628·0003
Battery
70
833
E-00658-000 1 Push Button 8witch
71
81-88,89-816,817-824,
E-00677
DIP8witch
825-832
73
E~00712
24 Pin Socket
74
E-00712-0001
40 Pin Socket
75
E-00712-0003
22 Pin Socket
77
J2
E-00715
15 Pi n Wafer Con nector
78
J1
E-00715-0004
28 Pin Wafer Connector
79
J3, J5
E-00715-0017
16 Pin Wafer Connector
80
J4
E-00715-0018
19 Pin Wafer Connector
81
J5
E-00715-0024
17 Pin Wafer Connector
NOTE 1:
When ordering, fill indash number. For example, AS-2962-0: LOST WORLD, AS-2962-2: SIX MILLION
09b~
MAN, AS-2962-3: PLAYBOY,AS-2962-4: VOLTAN,AS-2962-5: SUPERSONIC, AS-2962-6: STAR
TRF~i~~
2962-7: KISS, AS-2962-8: PARAGON,AS-2962-9: GROUND SHAKER, AS-2962-10 HARLEM GI;,~~~I~,~
TERS, AS-2962-12: DOLLY PARTON,AS-2062-13: SILVERBALLMANIA,AS-2962-16: ROLLING
SI~Sfr,: (
AS-2962-17: SPACE INVADERS
