XI. PARTS LIST
#1178 SPACE INVADERS
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-131
Bulbs, #44
E-125-22
Fuse,1 Amp. 3 AG Slow Blow (Playfield Solenoid Protection)
E-133-44
ASSEMBLY COILS
Coin Lockout
FO-3S-7000
Flipper (4)
AQ-25-500/
34-4500
Knocker
AR-26-1200
Outhole Kicker
AN-26-1200
Thumper-Bumper (3)
,
AN-26-1200
Sling-Shot (2)
AN-26-1200
Drop Target Reset
,
NO-26-1900
Single Drop Target
AR-26-1200
PLAYFIELD PARTS
See Figure II
MODULES
Lamp Driver A5
:
AS-2518-23
Display Driver A1 (5 used)
',
,
,
AS-2S18-21
Solenoid Driver/Voltage Regulator A3
AS-2518-22
MPU A4
,
AS-2962-17
Transformer & Rectifier A2
,. AS-2877-3
Rectifier Board (Part of A2)
AS-2518-49
Sound
,
AS-3022-S-
Auxiliary Lamp Driver A9
AS-2518-52
REPAIRS PROCEDURES/AIDS
Module & Component Replacement
F.O.560-1
AID (Assistance in Diagnostics)
Kit, used with F.O.560-1
KIT #485-1
MODULE COMPONENTS
SEE MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each Kit contains an assortment of the most needed electronic parts for use in Module repair.)
Kit #558-For Rectifier Board (Part of A2)
Kit #503-For MPU Board A4 (Less Memory U1-U6)
Kit #492-For Solenoid Driver/Voltage Regulator A3
Kit #493-For Display Driver A 1
Kit #494-For Lamp Driver A5
Kit #559-For Sound A8
20
