AS:
SOUND MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM DESIGNATION
PART NO.
DESCRIPTION
1 A8 (see note 1)
AS-3022-3
PWB Module Complete
2 Ul
E-620-124
Sound Chip AY-3-891 0
3 U2
E-620-29
PIA,
6820/21
4 U3
E-620-125 (E620-128) CPU, 6808 (6802 Note 3)
5 Ul0
E-620-30
Ram, 6810 (Note 3)
6 U5
E-620-33
Hex Inverter 4049B
7 U6
E-620-5
Quad 2 Input 4011 B
8 US
E-620-126
Amp, LM3900
9 U9
E-620-127
Power Amp, TDA 2002
10 Q1
E-585-31
Transistor,2N3904
11 CR1,2
E-587-6
Diode, 1N4004
12 SWl
E-658-1
Switch
13 C12
E-586-118
Cap .. 2MF::!::20%Y5p, 16 V
14 C2
E-586-130
Cap . .47
±20''Io
15 C16
E-586-83
Cap. 470 PF 50 V
16 C3
E-586-120
Cap. 68 PF, ::!::20%1K
17 C18,19
E-586-121
Cap. 27 PF, ::!::20%1K
18 Yl
E-744-5
Crystal, 3.579545 MHZ
i
19 J2
E-736-2
Connector, Wafer, 2 Pin KK156
20 Jl
E-736-15
Connector, Wafer, 15 Pin KK156
21 R9
E-105-196
Resistor, 1 Ohm,
%
w.,
5%
22 R8
E-105-211
Resistor, 2.2 Ohm,
1f4
w.,
5%
23 R7
E-l05-303
Resistor, 220 Ohm,
V4
v«,
5%
24 Rl
E-105-230
Resistor, 1 K,
1/4
w.,
5%
25 R21,22,23,24
E-105-238
Resistor, 3.3K. Ohm,
1/4
w.,
5%
26 R6
E-105-239
Resistor, 4.7K.,
1/4
w.,
5%
27 R3, 14, 15,16,
17,18,19,25
E-l05-185
Resistor, 10K.,
V4
w.,
5%
28 R2
E-105-245
Resistor, 30K.,
V4
w.,
5%
29 Rl0
E-105-252
Resistor, 180K.,
V4
w.,
5%
30 R4
E-l05-225
Resistor, 200K.,
V4
w.,
5%
31 R5,20
E-105-285
Resistor, 1M,
V4
w.,
5%
32 RTl
E-599-16
Potentiometer 1K
33 C23
E-586-122
Cap .. 001 ±20% 2SF
34 C15
E-586-123
Cap. 4700 MF
@
25 V
35 C7
E-586-124
Cap. 470 MF
@
6.3 V
36 C8
E-586-129
Cap. 470 MF@ 16 V
37 C5,13
E-586-90
Cap. 1 MF
@
50 V
38 C9. 1,14,6
E-586-89
Cap .. 1 MF
39 C4, 22,17,21,
20,24
E-586-85
Cap .. 01 MF
40 XU10, XU4
E-712
Socket, 24 Pin
~
41 XU1, XU2, XU3
E-712-1
Socket, 40 Pin
42 Used with 43
LSPR-00632-1106
Bolt, 6 x 32
X 3/8
43 Used with 42
N-00632-2112
Nut, 6 x 32
44
H.S for U9
E-682-8
Heat Sink, 6030BTT
45
Used with C15
E-647-5
Ty Rap
46 TP1, 2, 3, 4, 5, 6
P-5399
Test Point
47 Use with 44, 9
M-1834
Thermal Grease
I
48 Jumper, B
22 AWG Wire, Solid Tinned
W-1211c
Schematic
NOTE
1: When ordering specify name of game.
NOTE 2: 0
rder replacement memory chip U4 specifying name of game and part no. starnped
0
n chip.
NOTE 3:
When using item 4, 6808 you must use item 5, 6810and the "8" jumper. When item, 6802 is available
delete item 5 and use "A" jumper.
