AS-2S18-21 DISPLAY DRIVER MODULE
A1: DISPLAY DRIVER MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM QTY.
DESIGNATION
PART
#
DESCRIPTION
1
1
P-2948-296
P.C. Board, M-64S-392
3
7
Rl,R3,R5,R7,R9,Rl1,R34
E-l05-226
Resistor, lOOK
Q
4
13
R14, R16, R18, R20, R22,
E-105-227
Resistor, 300K
C!
R24,R26,R35,R36,R37,
R38,R39,R40
5
6
R43,R44,R45,R46,R47,
E-105-228
Resistor, 9.1 K
Q
R48
6
7
R13,R15,R17,R19,R21,
E-105-229
Resistor, 1.5K
Q
R23,R25
7
7
R27, R28, R29, R30, R31,
E-l05-230
Resistor, 1K
Q
R32,R33
8
1
R41
E-l05-231
Resistor, 39K
Q
9
1 R42
E-10S-271
Resistor, 240K Q
10
11
1
C2.
E-586-65
Capacitor, .01 MFD, SOOV
13
6
07, 08, 09,010,011,012
E-585-32
Trans islor (2N5401)
14
13
01, 02, 03, 04, OS, 06,
E-585-33
Transistor (MPS-A42)
013,014,015,016,017,
018,019
16
VRl
E-598-7
Zener Diode, HOV
17
Ul
E-620-38
I.C. Decoder
18
19
2
Jl
E-71S-34
10 Pin Wafer Pin Connector
21
1
DSl
E-680
Digital Display Panel
22
2
M-1836
Hi-Lo Screw, W/H
23
1
P-2399
Display Mounting (Top)
24
1
P-2399-1
Display Mounting (Bottom)
26
6
R2,R4,R6,R8,R10,R12
E-105--281
Resistor, 2.2K
n
27
6
R49,R50,R51,R52,RS3,
E-105-242
Resistor, 20K
n
R54
28 As
Wire Jumper
Reo'd
29
1
C1
E-S86-8S
Capacitor, .01 MFD, 25V
NOTE:
INTERCHANGEABLE WITH AS-2518-15
