A4: MPU MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITIM
DESIGNATION
PART
#
DESCRIPTION
1
A4 (see note 1)
AS-2962-13
MPU Module Complete.
Silverball Mania
2
A4 (see note 2)
AS-2518-35
MPU Module less Program
Memory, U1-6 incl.
3·32
See Schematic
Resistors, See schematic for value
33
C14, C15
E-00586-0067
Capacitor, 470 PFD, 1kv
34
C18
E·00586-0088
Capacitor, .05 MFD, 16V
35
C16
E-00586-00B1
Capacitor,.1 MFD, 100V
36
C4,C5
E-00586-0073
Capacitor, 4.5 MFD, 25V
37
C3, C6·C13, C17, C81
E-00586-0085
Capacitor, .01 MFD, 25V
38
C79, C41-C67
E·00586-0083
Capacitor, 470 PFD, 50V
39
C19-C31, C78, C33-C40
E·00586-0082
Capacitor, 390 PFD, 50V
40
C1, C2, C68-C77
E·OO586-0084 Capacitor, 820 PFD, 50V
41
C32
E-00586-0077
Capacitor, 3000 PF, 1kv
43
05
E-00585-0023
Transistor PNP (MPS-3702)
44
01,02
E-00585-0031
Transistor (2N3904)
47
CR44
E-00587-0006
Diode (IN4004)
48
CRi-CR7, CR11-CR43,
E-00587-0014
Diode (lN4148)
CR45-CR49
49
CR8
E-00679
LED (Green)
50
VRi
E-00598-000B Diode Zener (8.2V, IN9598)
52
L1,L2
E-00604·0003
Inductor, 22 Micro Hy.
53
U12
E-00620-0004
Timer (555)
54
U19
E-00620-0005
Quad 2 Input (4011)
55
U9
E-00620-0028
MPU I.C. (6800)
56
Ui0, Ui1
E-00620-0029
PIA I.C. (6820)
57
U7
E-00620-0030
RAM I.C. (6810)
59
U20
E-00620-0032
H EX Buffer I.C. (14502B)
60
U14,U18
E-00620-0033
HEX Inverter (4049B)
61
Ui5
E-00620-0034
Quad Memory Drive (MC3459L)
62
UiS
E-00620-0035
Dual Monostable (9602)
64
U17
E-00620-0041
Quad 21nputs (74LOON)
65
UB
E-00620-0042
RAM (C MOS, P5101L·3)
68
8T1,8T2,8T3
E-00628-0003
8attery
70
S33
E-00658-0001
Push Button Switch
71
81·88, S9·S16, S17-S24,
E·00677
DIP Switch
S25·832
73
E~00712
24 Pin Socket
74
E-00712-0001
40 Pin Socket
75
E-00712-0003
22 Pin Socket
77
J2
E-00715
15 Pin Wafer Con nector
78
J1
E-00715-0004
28 Pin Wafer Connector
79
J3, J5
E·OO715·0017
16 Pin Wafer Con nector
80
J4
E·OO715·0018
19 Pin Wafer Connector
81
J5
E·00715-0024
17 Pin Wafer Connector
NOTE 1;
When ordering, fill in dash number. For example. AS-2962-0: LOST WORLD, AS-2962-2: SIX MILLION DOLLAR
MAN, AS-2962-3: PLAYBOY, AS-2962-4: VOLTAN. AS-2962-5: SUPERSONIC,
AS-2962-6: STAR TREK.
AS-2962-7: KISS. AS-2962~8: PARAGON, AS-2962-9: GROUND SHAKER, AS-2962-10 HARLEM GLOBE-
TROTTERS, AS-2962-12: DOLLY PARTON, AS-2962-13: SILVERBALL MANIA
NOTE 2;
Order replacement memory chips U1-U6. specifying game, socket and part number stamped on chip.
22
