GAME #1157 SILVERBALL MANIA
(figure
V)
SOLENOID IDENTIFICATION TABLE
Self
Self
Test# SOLENOID IDENTIFICATION
Test # SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
07 LEFT THUMPER BUMPER
02 KNOCKER
08 RIGHT THUMPER BUMPER
03 KICK AND DOWN
09 CENTER THUMPER BUMPER
04 RIGHT SLINGSHOT
10 COIN LOCKOUT DOOR
05 LEFT SLINGSHOT
11
K1 RELAY (flipper enable)
06 UP KICKER
SWITCH ASSEMBLY SELF •.TEST DISPLAY NUMBERS
Self
Self
Test
#
SWITCH DESCRIPTION
Test
#
SWITCH DESCRIPTION
01 BOTTOM CENTER LANE
21
TOP "V" TARGET
02 HOPP A.O. BUnON (2)
22
TOP "L" TARGET
03 TOP RIGHT ROLLOVER
23 TOP
-r
TARGET
04 TOP CENTER ROLLOVER
24 TOP "S" TARGET
05 TOP LEFT ROLLOVER
25
RIGHT SPINNER
06 CREDIT BUTTON
26
"A" RIGHT OUT ROLLOVER
07
TILT (3)
27
RIGHT ''I'' RETURN R.O.
08 OUTHOLE KICKER
28
CENTER TARGET
09 COIN III (RIGHT)
29 "AULEFT RETURN R.O.
10
COIN I (LEFT)
30 "M" LEFT OUT A.O.
11
COIN II (MIDDLE)
31 LOWER "L" SIDE TARGET
12
32 UPPER "L" SIDE TAAGET
13
33 LEFT SPINNER
14
34 50 PT REBOUND (4) AND
TOP BUMPERS (4)
15
35 SERVICE Sw. (PANEL)
16 SLAM (2)
36
RIGHT SLINGSHOT
17
RIGHT "A" TARGET
37
LEFT SLINGSHOT
18 LEFT "B" TARGET
38
CENTER THUMPER BUMPER
19 LEFT "An TARGET
39
RIGHT THUMPER BUMPER
20 LEFT "E" TARGET
40 LEFT THUMPER BUMPER
NOTE: SLINGSHOT
&
THUMPER BUMPER COILS
WILL BE ENERGIZED WHEN SWITCH IS MADE.
