A-14876-R-3
Flipper Assembly
Item Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
A-14877-R
SW-1A-194
4701-00002-00
4105-01019-10
4008-01079-05
4701-00003-00
01-9375
20-6516
4010-01066-06
4701-00004-00
A-12390
FL-20867
01-7695-1
4006-01017-04
10-364
4006-01005-06
4406-01117 -00
Description
Item Part Number
Description
Flipper Base Assembly, Right
Switch Assembly
Lockwasher #6 Split
Sh. Metal Screw, #5 x
5/8"
Mach. Screw, 8-32 x
5/16"
Lockwasher #8 Split
Switch Mounting Bracket
Speednut, Tinnerman
Cap Screw, 10-32 x
3/8"
Lockwasher #10 Split
Flipper Stop Assembly
Flipper Coil, White
Solenoid Bracket
Mach. Screw, 6-32 x
1/4"
Spring
Mach. Screw, 6-32
x
3/8"
Nut 6-32 Hex.
18 A-15848-R
a) A-17050-R
b) A-15847
c) 02-4676
d) 4010-01086-14
e) 4700-00023-00
f)
4701-00004-00
g) 4410-01132-00
19 23-6577
20 03-7568
Crank Link Assembly, Right
Flipper Crank Assembly, Right
Flipper Link Assembly
Link Spacer Bushing
Cap Screw, 10-32 x 7/8"
Flat Washer,
5/8
x
13/64
x 16ga.
Lockwasher #10 Split
Nut 10-32 ESN
Bumper Plug,
5/8"
Flipper Bushing
Associated Parts:
(Not Shown)
21 23-6773
22 20-10290
Flipper Ring, Red
Flipper w/Shaft, Yellow
Flipper Notes ...
1. Each Flipper Assembly is mounted beneath the playfield, in conjunction with the Plastic Flipper
&
Shaft, and Flipper Rubber on the upper side of the playfield.
2. With the flipper, in the non-activated position, the E.o.S. Switch contacts must have a gap of .062 (±.015) inch. When flipper is activated switch must close.
3. Any adjustment of the E.o.S. switch must be made at a minimum distance of 0.25 inch from the switch body.
4. Longer blade of E.O.S. switch must be made straight.
Gap adjustment is done by adjusting shorter blade.
5. All
moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite
™
245
when reattaching screws to the Flipper Stop Assembly, the Solenoid Bracket, and the Flipper Bushing.
2-15
