IMPORTANT NOTICE
PLEASE READ
This pinball game is equipped with a SAFETY FEATURE to prevent shocks from the solenoid circuit
when the coin door is open. An interlock switch assembly (part no. A-18249-1), located at the left of the
coin door opening, has been added to the game. This assembly is a bracket containing the existing
memory protect switch on the bottom and a new interlock switch on the top. When the coin door is open,
the new interlock switch opens, breaking the connection to the +50V and +20V winding of the
transformer secondary.
A special tool called the Service Switch Actuator is provided for the serviceman/technician that repairs
the game. This toof is painted yellow and located in a bag stapled inside the cabinet. The Service
Switch Actuator slips over the interlock switch and holds it closed while the coin door is open, allowing
the serviceman to test and repair the solenoid circuit.
Hold the top interlock switch in, then slide the short end of the Service Switch Actuator over the top of the
interlock switch bracket and the long end over the center of the switch plunger to hold it in.
SERVICE SWI TCH ACTUA TOR _
(01-11791)
~
MEMORY PROTECT SWITCH --
(5643-09 268 -00)
BRACKET---
(01 -12676)
