Press the Up or Down buttons to cycle through the menu. Press the Enter button to access an
adjustment. Press the Up or Down buttons to see the setting choices. Press the Enter button to lock in a
choice. If a mistake is made, press Escape while "Saving Adjustment Value" is in the display. The
original settings is retained and the new value is ignored. Press the Escape button to return to the
Adjustment Menu.
A. ADJUSTMENTS MENU
A.1 Standard Adjustments
A.2 Feature Adjustments
A.3 Pricing Adjustments
A.4 H.S.T.D Adjustments
A.S Printer Adjustments (optional board required)
A.1 Standard Adjustments
A.1 01 Balls Per Game
A "game" is defined by specifying the number of balls to be played.
Range: 1-10
A.1 02 Tilt Warnings
The number of total actuation's of the plumb bob mechanism that can occur before the game is
"tilted".
Range: 1-10
A.1 03 Not Used
A.1 04 Not Used
A.1 05 Replay System
The type of replay system to be used.
Fixed - Replay value is set and does not change during game play.
Auto
% -
Replay starting value is set and changes every 50 games to comply with the
percentage of replays desired.
A.1 06 Replay Percent*
The percentage of replays the players are able to earn when Auto Replay is used.
Range: 5-50%
A.1 07 Replay Start*
The replay start value when Auto % Replay is used. The range of this setting is 500,000,000 to
9,500,000,000.
A.1 08 Replay Levels*
The number of replay levels used by the Auto
%
Replay mode. The range of this setting is 1 to
4. When two replay levels are chosen, the second replay level is automatically adjusted to twice
the starting replay level value. When three of four replay levels are chosen, their values are
automatically adjusted to three or four times the starting replay level.
"'ForAuto
%
Replay.
1-26
