RAISING THE PLAYFIELD
&CAUTION
Do not raise the playfield straight up! This game uses a slide assembly to raise and lower the
playfield.
Before Raising the Playfield:
Make sure there are no balls present in the ball trough or any of the other ball-holding playfield
devices (i.e. poppers). Raising the playfield with balls present in these locations may cause them
to come loose and damage the playfield. Use "Empty Balls Test" to remove all of the balls from
these locations.
To Raise Playfield:
1. Grasp bottom arch and carefully lift up playfield only high
enough to clear support brackets.
Slide Bracket
(2 used)
-::;~::::.....c~:"'_SU!lpott
Bradtet
(2 used)
PlayfieJd Track
(2 used)
3. Rotate playfield to upright service position (lean on backbox) by
pulling toward you and up.
2. Pull the playfield out toward you until it stops (rest position).
5. Push back playfield into cabinet and into playing position.
To Lower Playfield:
4. Rotate the playfield to the rest position.
1-6
