DIP SWITCH SETTINGS
AND JUMPERS
1MEG, 2MEG, 4 MEG EPROM
EPROM Jumper Settin s for G11
Dip Switch Chart
Country
SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
America
Off Off On On On On On On
European Off Off On On On Off On On
French
Off Off On On On On Off Off
German
Off Off On On On On On Off
Spain
Off Off On On Off On On On
SOLENOID/FLASHER TABLE
Sol.
Function
Solenoid
Voltage Connections
Drive
Drive Connections
Drive
Solenoid Part number
No.
Type
Xister
Wire
Flashlamp Type
Playfield Backbox Cabinet
Playfield Backbox Cabinet
Color
Playfield
Backbox
01 BIG KICK
High Power
J133-2
Q72
Jl16-1
Vio-Brn
AE-24-900
02 RIGHT TOKEN TUBE
High Power
J13S-2
Q6S
JllS-2
Vio-Red
04-10424
03 VARI TARGET RESET
High Power
J133-2
Q71
J116-4
Vio-Org SMl-26-600
04 LEFT TOKEN TUBE
High Power
J13S-2
Q67
JllS-S
Vio-Yel
04-10424
OS BANK KICK
High Power
J133-2
070
J116-6
Vio-Grn
AE-23-S00
06 OP POPPER UP
High Power
J133-2
Q66
J116-7
Vio-Blu
AE-24-900
07 RAMP DIVERTER
High Power
J133-2
Q69 Jl16-S
Vio-Blk
AE-26-1S00
OS KICKBACK (RAMP)
High Power
J133-2
Q65
Jl16-9
Vio-Gry
AE-23-S00
09 ROUGH EJECT
Low Power
J133-3
Q44
Jl13-1
Brn-Blk
AE-26-1500
10 LEFT SLINGSHOT
Low Power
J133-3
Q4S
J113-3
Brn-Red AE-26-1200
11 RIGHT SLINGSHOT
Low Power
J133-3
Q43
Jl13-4
Brn-Org_ AE-26-1200
12 LEFT JET
Low Power
J133-3
Q47 J113-5
Brn-Yel
AE-26-1200
13 RIGHT JET
Low Power
J133-3
Q42
J113-6
Brn-Grn AE-26-1200
14 TOP JET
Low Power
J133-3
Q46 J113-7
Brn-Blu
AE-26-1200
15 TOP LEFT 3-BANK
Low Power
J133-3
Q41
J113-8
Brn-Vio
AE-26-1200
16 TOP RIGHT 3-BANK
Low Power
J133-3
Q45
J113-9
Brn-Gry
AE-26-1200
17 BACK LEFT
Flasher
J133-6
Q28
Jl11-1
Blk-Brn
#906
18 ETS & BACK RIGHT (2)
Flasher
J133-6
Q32
J111-2
Blk-Red
#89,#906
19 RIGHT MIDDLE
Flasher
J133-6
Q27 J111-3
Blk-Org
#906
20 RIGHT BOTTOM
Flasher
J133-6
Q31
J111-4
Blk-Yel
#906
21 LEFT MIDDLE
Flasher
J133-6
Q26 J111-5
Blu-Brn
#906
22 LEFT BOTTOM
Flasher
J133-6
Q30
J111-6
Blu-Red
#906
23 LIGHT ROPE 1
Flasher
J134-S
Q25
J112-8
Blu-Org
04-10440
24 LIGHT ROPE 2
Flasher
J134-S
Q29
Jl12-9
Blu-Yel
04-10440
25 OP POPPER EJECT
Gen. Purpose
J133-1
Q16
Jl09-1
Blu-Grn
AE-27-1200
26 OP LIGHT & MOTOR
Gen. Purpose
J140-2
Q15
Jl09-2
Blu-Blk
20-10307
27 BOTTOM LEFT 3-BANK
Gen. Purpose
J133-1
Q14
J109-3
Blu-Vio
AE-26-1200
28 BOTTOM RIGHT 3-BANK Gen. Purpose J133-1
Q13
Jl09-4
Blu-Gry
AE-26-1200
35 AUTO PLUNGER
High Power
J119-8,9
Q81 J120-3
Yel-Gry
AE-23-800
36 LOCK UP RELEASE
Low Power
J119-8,9
Q83 J120-1
IOrg-Gry_ AE-26-1200
37 AUX. LAMP ENABLE
aL.P.D.C.
J138-2
Jl10-1
Brn-Whl
A-20909
38 AUX. LAMP CLOCK
aL.P.D.C.
J138-2
Jl10-3
IOrg-Wht
A-20909
39 AUX. LAMP DATA 1
aL.p.D.C.
J138-2
J110-4
Yel-Wht
A-20909
40 AUX. LAMP DATA 2
aL.P.D.C.
J138-2
Jl10-5
Grn-Wht
A-20909
General Illumination
01 ILLUMINATION STRING 1
G.\.
Jl05-1
Jl06-1
Q5
Jl05-7
Jl06-7
Wht-Brn
#44
#555
02 "AUX. LAMP 1 POWER
G.\.
Q4
Jl06-8
Wht-Org
#555
03 ILLUMINATION STRING 3
G.\.
Jl05-3
Jl06-3
Q3 Jl0S-9 Jl06-9
wht-Yel
#44
#555
04 "AUX LAMP 2 POWER
G.\.
Q2
Jl06-10
[Wht-Grn
#555
05 "AUX LAMP 3 POWER
G.\.
Ql
Jl06-11
[Wht-Vio
#555
Flipper Circuits
Voltage
Drive
Drive
Drive Wire
Coil
Coil
Connections
Transistors
Connectors
Colors
Part No.
Color
Playfield
Power
Hold
Playfield
Power
Hold
29
Lwr. Rt. Power J119-1 (Red-Grn) Q90
J120-13
Yel-Grn
30 Lower Right Flipper
Lwr Rt. Hold J 119-1 (Red-Grn
Q92
J120-11
Org-Grn
FL-20867
WHITE
31
Lwr. Lt. Power J 119-4 (Red-Blu) Q87
J120-9
Yel-Blu
32 Lower Left Flipper
Lwr. Lt. Hold J 119-4 (Red-Blu)
Q89
J120-7
Oro-Btu
FL-20867
WHITE
33
Upr. Rt. Power J 119-6 (Red-Vio) Q84
J120·6
Yel-Vio
34 Upper Right Flipper
Upr. Rt. Hold
Jl19-6
(Red·Vio)
086
J120-4
Orq-Vio
FL·11753
YELLOW
35
U_j)f Lt. Power J 119-8 (Red·Gry) 081
J120-3
Yel·Gry
SEE
ABOVE
36 U_P_jl_erLeft Flipper
Upr. Lt. Hold J119-8 (Red-Gry)
Q83
J120-1
Org-Gry
SEE
ABOVE
J 1xx = Power Driver Board: 24·6S49=#44 bulb; 24·8704=#89 bulb; 24-8768=#555 bulb; 24-8802=#906 bulb
"These G.\. strings do not brighten and dim, they are always ON.
ot,
P.D.C. = Low Power Device Controls
