J206-1 Green-Brown, Sw. Col. 1, to Playfield Sw.
J206-2 Green-Red, Sw. Col. 2, to Playfield Sw.
J206-3 Green-Orange, Sw. Col. 3, to Playfield Sw.
J206-4 Green-Yellow, Sw. Col. 4, to Playfield Sw.
J206-5 Green-Black, Sw. Col. 5, to Playfield Sw.
J206-6 Green-Blue, Sw. Col. 6, to Playfield Sw.
J206-7 Green-Violet, Sw. Col. 7, to Playfield Sw.
J206-8 Key
J206-9 Green-Gray, Sw. Col. 8, to Playfield Sw.
J207 -1 Not Used
J207-2 Not Used
J207-3 Not Used
J207-4 Not Used
J207 -5 Not Used
J207-6 Not Used
J207 -7 Not Used
J207-8 Key
J207-9 Green-Gray, Sw. Col. 8, to Backbox Sw.
J208-1 White-Brown, Sw. Row 1, to Playfield Sw.
J208-2 White-Red, Sw. Row 2, to Playfield Sw.
J208-3 White-Orange, Sw. Row 3, to Playfield Sw.
J208-4 White-Yellow, Sw. Row 4, to Playfield Sw.
J208-5 White-Green, Sw. Row 5, to Playfield Sw.
J208-6 Key
J208-7 White-Blue, Sw. Row 6, to Playfield Sw.
J208-8 White-Violet, Sw. Row 7, to Playfield Sw.
J208-9 White-Gray, Sw. Row 8, to Playfield Sw.
J208-10 Not Used
J208-11 Black-Violet, F5, to Upr Right E.O.S. Sw.
J208-12 Black-Blue, F3, to Lwr Left E.O.S. Sw.
J208-13 Black-Green, F1, to Lwr Right E.O.S. Sw.
J208-14 Orange, Ground to E.O.S. Sw.
J209-1 White-Brown, Sw. Row 1, to Backbox Sw.
J209-2 White-Red, Sw. Row 2, to Backbox Sw.
J209-3 Not Used
J209-4 Not Used
J209-5 Not Used
J209-6 Key
J209-7 Not Used
J209-8 Not Used
J209-9 Not Used
J210-1 Black, Ground, to/from J101-7, J606-1
J210-2 Key
J210-3 Black, Ground, to/from J101-5, J606-3
J210-4 Gray, +5V, to/from J101-4, J606-4
J210-5 Gray, +5V, to/from J101-3, J606-5
J210-6 Gray-Green, +12V, to/from J101-2, J606-6
J210-7 Gray-Green, +12V, to/from J101-1, J606-7
J211 34-Pin Ribbon Cable, Data to/from J102
J212-1 Green-Brown, Sw. Col. 1, to Coin Door Board J3-1
J212-2 Green-Red, Sw. Col. 2, to Coin Door Board J3-2
J212-3 Not Used
J212-4 White-Brown, Sw. Row 1, to Coin Door Board J3-3
J212-5 Key
J212-6 White-Red, Sw. Row 2, to Coin Door Board J3-4
J212-7 White-Orange, Sw. Row 3, to Coin Door Board J3-5
J212-8 White-Yellow, Sw. Row 4, to Coin Door Board J3-6
J212-9 Black-Blue, F8, Coin Door Board J13-2
J212-10 Black-Yellow, F6, to Right Flipper Opto Board J1-1
J212-11 Blue-Gray, F4, to Left Flipper Opto Board J1-2
J212-12 Blue-Violet, F2, to Right Flipper Opto Board J1-2
J212-13 Orange, Ground to Right Flipper Opto Board J1-4
