GAME #1187 ROLLING STONES (Figure V)
SOLENOID IDENTIFICATION TABLE
Self
Self
Test
#
SOLENOID IDENTIFICATION
Test
#
SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
09 RIGHT DROP TARGET
"ft:.'
(TOP)
02 KNOCKER
10 RIGHT DROP TARGET "B"
03 LEFTTHUMPER BUMPER
11 RIGHT DROP TARGET "C"
04 RIGHT THUMPER BUMPER
12 RIGHT DROP TARGET "0'
05 BOTTOM THUMPER BUMPER
(BOnOM)
06 LEFT SLINGSHOT
13 4 DROP TARGET RESET
07 RIGHT SLINGSHOT
14 COIN LOCKOUT DOOR
08 SAUCER KICKER
15 KI RELAY (FLIPPER ENABLE)
16 SAUCER DROP TARGET
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
Switch
Switch
Self
Self
Test
#
DESCRIPTION
Test
#
DESCRIPTION
01
21 DROP TARGET #4 (BOTTOM)
02
22 DROP TARGET #3
03
23 DROP TARGET #2
04
24 DROP TARGET #1 (TOP)
05
25
06 CREDIT BUTTON
26 RIGHT SIDE RO. BUDON
07 TILT (3)
27 LEFT SIDE R.O. BUDON
08 OUTHOLE
28 #5 TARGET
09 COIN III (RIGHT)
29 #4 TARGET
10 COIN I (LEFT)
30 #3 TARGET
11 COIN II (MIDDLE)
31 #2 TARGET
12 #1 TARGET
32 SAUCER
13 SAUCER DROP TARGET
33 50 POINT REBOUND AND
14 RIGHT OUTLANE
SCORING MINI POST (2)
15 LEFT OUTLANE
34 FLIP/FEED LANE (RT)
16 SLAM (2)
35 FLIP/FEED LANE (LT)
17 "K" ROLLOVER
36 RIGHT SLINGSHOT
18 "C" ROLLOVER
37 LEFT SLINGSHOT
19 "0" ROLLOVER
38 BODOM THUMPER BUM.
20 "R" ROLLOVER
39 RIGHT THUMPER BUM.
40 LEFT THUMPER BUM.
NOTE: SLINGSHOT
&
THUMPER BUMPER COILS
WILL BE ENERGIZED WHEN SWITCH IS MADE.
17
