Coin Door Assembly
USA Door with
decals,
pin
C-13155-1
2-Chute Door - 09·17002-x
3-Chute Door - 09·17003-x
("x" is the country designator)
Item Part Number
Description
Quantity
1 27-1038
Button Cover
20r3
2 27-1041-1-54
Price Panel
20r3
3 27-1026-1- 15 Coin Entry Plate
2 or 3
4 27-1016
Lock Assembly
1
5 27-1061-1
Coin Return - Bezel
1
6 27-1062
Coin Return Flap
1
7 27-1021
Button Housing - 2-slot
1
27-1022
Button Housing - 3-slot
1
8 27-1111
Interlock Switch
1
9 27-1006-1
Coin Door, 2-Slot
1
27-1007-1
Coin Door, 3-Slot
1
10 27-1005
Coin Door Frame
1
11 27-1003
MlC Screw, 6-32 x
3/16
4
12 27-1008
Diagnostic Switch
1
13 27-1101
MlC Screw, 4-40 x
1/4
2
14 27-1102
Bracket, Diagnostic Switch
1
15 27-1037
Button
20r3
16 27-1078
M/C
Screw, 6-32 x
3/8
20r3
17 27-1039
Conical Spring
20r3
18 27-1079
Self-tapping Screw, #6 x
1/4
2
19 27-1077-1
Coinbox Cover
1
20 27-1066
Slam Switch
1
21 27-1067
M/C
Screw, 4-40 x 112
2
22 27-1017
Nut (key)
1
23 27-1012
Locking Cam
1
24 27-1011
Locking Arm
2
25 27-1020
Washer
1
26 27-1018
Star Washer
1
27 27-1019
M/C
Screw,
1/4-28
x
5116
1
28 Not Used
29 Not Used
30 27-1112
Coin Inlet Chute
2 or3
31 27-1088
Cable Clamp
2 or3
32 27-1025
Key Hook
1
33 27-1086
Washer, #6
2 or 3
34 27-1078
M/C
Screw, 6-32 x
3/8
1 or 2
'-
27-1113
~MlC Screw, 6-32 x
7/16
1
35 27-1079
Self-tapping Screw, #6 x
1/4
2 or3
36 27-1084
Lamp Socket
2 or3
27-1085
Lamp
20r3
37 27-1096
Self-tapping Screw, #5 x
3/8
2 or3
38 27-1087
MlC Screw, 6-32 x
5/8
2 or3
39 27-1082
Lever Arm
2 or 3
40 27-1097
Switch Cover
20r3
41 27-1091-1
Coin Accept Chute
2 or3
42 27-1075
Wire Form (Small)
2or3
or
27-1093
Wire Form (Large)
43 27-1094
M/C
Screw, 4-40 x
7/8
4 or 6
44 27-1087
MlC Screw, 6-32 x 5/8
40r 6
45 27-1086
Washer, #6
4 or 6
46 27-1095
Nut, 4-40 ESNA
40r 6
47 27-1076-1
Coin Return Box
1
48 27-1078
MlC Screw, 6-32 x
3/8
2
49 27-1092
Microswitch
2or3
ROLLERGAMES 66
