LOCK Kickback
Assy
pin 8-13497
7
Item Part Number
1 A-13270
2 A-13498
3 01-8-508-T
4 10-135
5 01-9597
6 23-6420
7 AE-23-800
8 4008-01017-04
9 03-7067
10 4008-01017-06
11 4408-01119-00
Description
Bell Armature
Mounting Bracket Assy
Solenoid Bracket
Solenoid Spring
Base Plate
Rubber Grommet
Coil Assembly
Mach. Screw, #8-32 x 1/4
Coil Tubing
Mach. Screw, #8-32 x 3/8
Nut, #8-32 ESN
Upper Lelt Kickback Assy
pin 8-13499
Item Part Number
Description
1 A-6306-2
Bell Armature Assembly
2 01-9595-1
Kicker Mounting Bracket
3 01-8-508-T
Solenoid Bracket
4 10-135
Solenoid Spring
"_
5 23-6420
Rubber Grommet
6 AE-24-900
Coil Assembly
7 4008-01017-04 Mach. Screw, #8-32 x 1/4
8 03-7067-5
Coil Tubing
ROLLERGAMES 64
