13 f) 1.)
13 f) 2.)
13 f) 3.)
02-4219
20-9370-1
03-8050-1
Coil Plunger
Spring Pin, 5/32 dia.
x
7/16
Flipper Link
Lowe,r
Righ ',
Flipper
Assy
pin C-11626-R-3
Item Part Number
Description
Hem Part Number
Description
1
HW-30018-6
Wire, 18 AWG, Blue
g)
B-10657-R
Flipper Crank Assy, R.
2
03-7520-2
Ty-Wrap, Nylon
1.) 01-8073-R
Flipper Crank, R.
3
20-6516
Speednut, Tinnerman
2.)
17-1037
Crank Washer
4
5045-12098-00
Capacitor, 2.2 J.LFd,250V, 20
3.) 010-01066-18
Cap Screw,10-32x1-1/8
5
RM-21-06
Sleeve, Vinyl (Cap. leads)
4.) 4410-01127-00 Nut, 10-32 Hex Hd.
6
4010-01066-06
Cap Screw, 10-32 x 318, SH
5.) 4700-00107-00 ,Washer,
5/80.d.x13/64
7
4701-00004-00
Lockwasher, #10 Split
l.d.
x
12ga.
8
A-12111
Flipper Stop Assembly
6.) 4701-00004-00 Lockwasher, #10 Split
9
FL-11630
Flipper Coil (Red)
7.) RM-23-06
Tubing,
H.
S.
1/4
DWP
10 4006-01017-04
Mach. Screw, 6-32
x
1/4
14 23-6577
Bumper Plug
11 01-7695
Solenoid Bracket
15 03-7568
Flipper Bushing
12 10-376
Coil Plunger Spring
16 4006-01 005-06 Mach. Screw, 6-32
x
3/8
13 B-10655-R
Crank Link Assembly, Right
17 4406-01117-00 Nut, 6-32 Hex.
a) 02-4179
Link Spacer Bushing
18 C-11627-R
Flipper Base Assy, R.
b) 4010-01086-14
Cap Screw, 10-32
x
7/8,
SH 19 06-14G
Insulating Blade
c) 4700-00023-00
Washer,
5/8 x13/64
x16ga.
20 4105-01019-10 Sh. Metal Screw, #5 x
5/8
d) 4701-00004-00
Lockwasher, #10 Split
21 4701-00002-00 Lockwasher, #6 Split
e) 4410-01132-00
Nut, 10-32 ESNA
22 23-6622
Tape, Double-sided
f) A-10656""
Flipper Link Assembly
23 03-7811
End of Stroke (EOS) Sw
1.) 02-4219
Coil Plunger
2.) 20-9370-1
Spring Pin, 5/32 dia. x 7116
3.) 03-8050-1
Flipper Link
"" Also See Separate Diagram
Associated Parts:.
20-9250-5
Flipper Arm on Shaft
23-6519-4
Red Rubber Ring
Fllpp ier
lJnk
Assembly
plnA-10656
[Items listed refer to items listed "for C·11626-R·3]
Hem Part No.
Description
ROLLERGAMES 52
