MENU SYSTEM OPERATION
The Main Menu allows you to choose from several categories, which in tum lead to other menus to choose from. To
access the Main Menu, open the coin door and press the Begin Test button, then press the Enter button. Press the
Up or Down buttons to cycle through the Main Menu. Press the Enter button to access a menu. Press the Escape
button to return to the Main Menu. Press the Start button for HELP at any time.
MAIN MENU
B. BOOKKEEPING MENU
B.l Main Audits
B.2 Earnil}9_Audits
B.3 Standard Audits
B.4 Feature Audits
B.5 Histograms
B.6 Time-Stamps
P. PRINTOUTS MENU
P.1 Earning_s Data
P.2 Main Audits
P.3 Standard Audits
P.4 Feature Audits
P.5 Score Histograms
P.6 Time Histograms
P.7 Time-Stamps
P.8 All Data
T. TEST MENU
T.l
Switch Edges Test
T.2 Switch Levels Test
T.3 Single SWitches Test
T.4 Solenoid Test
T.5 Flasher Test
T.6 General Illumination Test
T.7 Sound and Music Test
T.8 Single Lamp Test
T.9 All Lamps Test
T.l0 Lamp and Flasher Test
T.ll
DisplayTest
T.12 Flipp_erCoil Test
T.13 Ordered Lamps Test
T. 14 Lamp Row-Col
T.15 DIP Switch Test
T.16 Dozer Test
T.17 "TED" Test
T.18 "RED" Test
T.19 Motor/Switch
T.20 Empty Balls
U. UTILITIES MENU
U.l
Clear Audits
U.2 Clear Coins
U.3 Reset H.S.T.D.
U.4 Set Time and Date
U.5 Custom Message
U.6 Set Game I.D.
U.7 Factory Adjustments
U.8 Factory Resets
U.9 Presets
U.l0 Clear Credits
U.ll
Auto Burn-in
A. ADJUSTMENT MENU
A. 1 Standard Adjustments
A.2 Feature Adjustments
A.3 Pricing Adjustments
A.4 H.S.T.D. Adjustments
A.5 Printer Adjustments
1-8
Press Escape
To move out of a menu selection.
Press Enter
To get into a menu selection.
Press Up
Increases sequence;
(ex.
A.1,
A.2.
A.3,
AA).
Press Down
Decreases sequence;
(ex. A.4, A.3, A.2, A.l).
Use Up or Down to cycle through
the menu selections.
Use Escape and Enter to move
into and out of the selected menu.
