Power Driver Board Continued ...
J114-1 Gray-Green, +12V to J210-6, 7; J904-2
J114-2 Gray-Green, + 12V to J210-6, 7; J904-2
J114-3 Gray, +5V to J210-4, 5; J3-1,3; J904-1
J114-4 Gray, +5V to J210-4, 5; J3-1,3; J904-1
J114·5 Black, ground to J210-1, 3; J3-4, 5; J904-4, 5
J114-6 Key
J114-7 Black-White, ground to J21O-1,3; J3-4, 5;.
J904-4,5
J115·1 Yellow-White, 6.8Vac from xformer secondary
J115-2 White-Brown, 6.8Vac from xformer secondary
J115-3 White-Brown, 6.8Vac from xformer secondary
J11S-4 White-Orange, 6.8Vac from xformer secondary
J115-S White-Yellow, 6.8Vac from xformer secondary
J115·6 White-Yellow, 6.8Vac from xformer secondary
J115- 7 Orange, 6.8Vac from xformer secondary
J115-8 Orange, 6.8Vac from xformer secondary
J115-9 Key
J11S·10 Green, 6.8Vac from xformer secondary
J 115·11 Brown, 6.8Vac from xformer secondary
J115-12 Brown, 6.8Vac from xformer secondary
J116-1 Key
J116·2 Gray-Yellow, +12V to Coin Door Board J2-2
J116-3 Black, ground to Coin Door Board J2-1
J116-4
N/C
J117·1 Key
J117·2 Gray-Yellow, +12V to Dot Matrix Cntrllr J606-7
J117-3 Black, ground to Dot Matrix Cntrllr J606-3
J117-4 Gray, +5V to Dot Matrix Cntrllr J606·5
J118-1 Key
J118-2 Gray-Yellow, +12V to playfield boards
J 118-3 Black, ground to playfield boards
J118-4
N/C
J119-1 White-Violet, 6.8Vac, G.t. to Coin Door BrdJ2-5
J119-2 Key
J119-3 Violet, return, G.t. to Coin Door Board J2·3
J120·1 Brown, return, G.t. to playfield
J120·2 Orange, return, G.t. to playfield
J120-3 Yellow, return, G.I. to playfield
J120-4 Key
J120·5 Green, return, G.t. to playfield
J120-6 Violet, return, G.t. to playfield
J120-7 White-Brown, 6.8Vac, G.I. to playfield
J120-8 White-Orange, 6.8Vac, G.t. to playfield
J120-9 White·Yellow, 6.8Vac, G.t. to playfield
J120-10 White·Green, 6.8Vac, G.t. to playfield
J120-11 White-Violet, 6.8Vac, G.t. to playfield
J121-1 Brown, return, G.I. to insert panel
J121-2 Orange, return, G.I. to insert panel
J121-3 Yellow, return, G.t. to insert panel
J121-4 Key
J121-5
N/C
J121~6 N/C
J121-7 White·Brown, 6.8Vac, G.t. to insert panel
J121-8 White-Orange, 6.8Vac, G.t. to insert panel
J121-9 White-Yellow, 6.8Vac, G.t. to insert panel
J121-10
N/C
J121-11
N/C
J122-1 Blue-Brown, solenoid 25 drive to coil
J 122-2 Blue-Red, solenoid 26 drive to coil
J122-3 Blue-Orange, solenoid 27 drive to coil
J122-4 Blue-Yellow, solenoid 28 drive to coil
J 122-5 Red-Orange, tieback for solenoid 25
J122-6 Red-Orange, tieback for solenoid 26
J122-7 Key
J122-8 Red-Orange, tieback for solenoid 27
J122-9
N/C
J123- Not Used
J124- Not Used
J125- Not Used
J126-1 Black-Brown, solenoid 17 drive to coil
J126-2 Black-Red, solenoid 18 drive to coil
J126-3 Black-Orange, solenoid 19 drive to coil
J126-4 Black-Yellow, solenoid 20 drive to coil
J126-5 Blue-Green, solenoid 21 drive to coil
J126-6 Blue-Black, solenoid 22 drive to coil
J126-7 Blue-Violet, solenoid 23 drive to coil
J126-8 Blue-Gray, solenoid 24 drive to coil
J126-9 Key
J126-10
N/C
J126-11 Red-Orange, tieback for solenoid 24
J 126-12 Red-Orange, tieback for solenoid 22
J 126-13 Red-Orange, tieback for solenoid 21
J127-1 Brown-Black, solenoid 9 drive to coil
J127-2 Key
J127-3 Brown-Red, solenoid 10 drive to coil
J 127-4 Brown-Orange, solenoid 11 drive to coil
J127-5 Brown-Yellow, solenoid 12 drive to coil
J127-6 Brown-Green, solenoid 13 drive to coil
J127-7 Brown-Blue, solenoid 14 drive to coil
J127-8 Brown-Violet, solenoid 15 drive to coil
J127-9 Brown-Gray, solenoid 16 drive to coil
J128-Not Used
J129-Not Used
J130-1 Violet-Brown, solenoid 1 drive to coil
J130-2 Violet-Red, solenoid 2 drive to coil
J130-3 Key
J130-4 Violet-Orange, solenoid 3 drive to coil
J130-5 Violet-Yellow, solenoid 4 drive to coil
J130-6 Violet-Green, solenoid S drive to coil
J130-7 Violet-Blue, solenoid 6 drive to coil
J 130-8 Violet-Black, solenoid 7 drive to coil
J 130·9 Violet-Gray, solenoid 8 drive to coil
J131- Not Used
J 132- Not Used
3-37
