Security CPU Board Assembly
A-17651-50024
21
0 "0000000
0"
126
(I.
" aOOOOlll
l oaaaco
.25
J201
U
o
J2D2
I
,-m~
~
.
o
c
o
o
o
m
-
c;
~
o
c
o
"
I
I
J
I
I
J212
J208
J206
1000.0000110.000000011000.000001
8
1 9
1 9
1
J205
J207
J209
pO.OOOOOOQQoj
jO.ooooooollooo.oooool
12
T 9
1 9
1
J201,
26-pin ribbon cable, data tolfrom J602
J202,
34-pin ribbon cable, data tolfrom J903; Pl; J601
J203- Not Used
J204 26-pin ribbon cable, data to/from Jl Aux. Driver Board
J205-1 Orange-Brown, ded. sw. row 1, to Coin Door Brd J1-8
J205-2 Orange-Red, ded. sw. row 2, to Coin Door Brd Jl-7
J205-3 Orange-Black, ded. sw. row 3, to Coin Door Brd Jl-6
J205-4 Orange-Yellow, ded. sw. row 4, to Coin Door Brd Jl-5
J205-5 Key
J205-6 Orange-Green, ded. sw. row 5, to Coin Door Brd Jl-4
J205-7 Orange-Blue, ded. sw. row 6, to Coin Door Brd Jl-3
J205-8 Orange-Violet, ded. sw. row 7, to Coin Door Brd Jl-2
J205-9 Orange-Gray, ded. sw. row 8, to Coin Door Brd J1-1
J205-10 Black, ground, to Coin Door Brd J1-10
J205-11 N/C
J205-12 Orange-White, switch enable, to Coin Door Brd J1-11
J206- Not Used
J207-1 Green-Brown, switch column 1, to playfield switches
J207·2 Green-Red, switch column 2, to playfield switches
J207-3 Green-Orange, switch column 3, to playfield switches
J207-4 Green-Yellow, switch column 4, to playfield switches
J207-S Green-Black, switch column 5, to playfield switches
J207-6 Green-Blue, switch column 6, to playfield switches
J207-7 Green-Violet, switch column 7, to playfield switches
J207-8 Key
J207-9 Green-Gray, switch column 8, to playfield switches
J207-10 NlC
J207-11 NlC
J208- Not Used
J209-1 White-Brown, switch row 1, to playfield switches
J209-2 White-Red, switch row 2, to playfield switches
J209-3 White-Orange, switch row 3, to playfield switches
J209-4 White-Yellow, switch row 4, to playfield switches
J209-5 White-Green, switch row S, to playfield switches
J209-6 Key
J209-7 White-Blue, switch row 6, to playfield switches
J209·8 White-Violet, switch row 7, to playfield switches
J209-9 White-Gray, switch row 8, to playfield switches
J210-1 Black, ground, from Power Driver Board J1 14-5,7
J210-2 Key
J210-3 Black, ground, from Power Driver Board J1 14-5, 7
J210-4 Gray, +5V, from Power Driver Board J1 14-3,4
J210-S Gray, +5V, from Power Driver Board J114-3, 4
J210-6 Gray-Green, +12V, from Power Driver Board Jl14-1, 2
J210-7 Gray-Green, +12V, from Power Driver Board J1 14-1,2
J211,
34-pin ribbon cable, data tolfrom Jl13
J212-1 Green-Brown, switch col. 1, to Coin Door Board J3- 1
J212-2 Green-Red, switch col. 2, to Coin Door Board J3-2
J212-3 NlC
J212-4 White-Brown, switch row 1, to Coin Door Board J3-3
J212-5 Key
J212-6 White-Red, switch row 2, to Coin Door Board J3-4
J212-7 White-Orange, switch row 3, to Coin Door Board J3-5
J212-8 White-Yellow, switch row 4, to Coin Door Board J3-6
J213-1 Black, to battery holder board J 1-1
J213-2 Black, to battery holder board J1-2
J213-3 Key
J213-4 Gray, to battery holder board Jl-4
J213-5 Gray, to battery holder board Jl-5
J1-1 Black, from CPU J213-1
Jl-2 Black, from CPU J213-2
J1-3 Key
J1-4 Gray, from CPU J213-4
Jl-5 Gray, from CPU J213-5
