Solenoid/Flashlamp Locations
CoillFlasher
Assemblx
Item Number
Number
Description
01 AE·26·1500
A·18753
Trough
02 AE·26·1500
A·19049
Lower Lt. Diverter
03 AL·26·1500
A·18794
Lock-Up Pin
04 AE·26·1200
A·19041
Upper Lt. Diverter
05 AE·26·1200
A·18948
Upper Rt. Diverter
06 AE·24·900
A·19046
Start City
07 AE·23·800
8·10686·1
Knocker
08 AE-24·900
A·18794
Lock Kickout
09 SM-30-1100 A-19128
Ted Eyes Left
10 SM-30-1100 A-19128
Ted Lids Down
11 SM-31-900
A-19128
Ted Lids Up
12 SM-30-1100 A-19128
Ted Eyes Right
13 SM-30-1100 A-19127
Red Lids Down
14 SM-30-1100 A-19127
Red Eyes Left
15 SM-31-900
A-19127
Red Lids Up
16 SM-30-1100 A-19127
Red Eyes Right
17 A-13997
A-19129-1
Red Motor On
18 A·13997
A-19129-1
Red Motor Direction
19 A-13997
A-19129
Ted Motor On
20 A-13997
A-19129
Ted Motor Direction
21 AE-26-1200
B-9362-L-2
Left Slingshot
22 AE·26-1200
B-9362·R-3
Right Slingshot
23 14-8016
A-18832
Bulldozer Motor
24 AE·26-1500
A-13941
Red Eject
25 AE-26-1200
A-9415-2
Top Jet Bumper
26 AE-26-1200
A·9415-2
Left Jet Bumper
27 AE-26-1200
A-9415·2
Right Jet Bumper
28 14-7951
A-19169
Shaker Motor
FLIPPER
29-30 FL-15411
A-15849-R-4 Lower Right Flipper
31-32 FL-15411
A·15849·L·4 Lower Left Flipper
33-34 FL-11753
A-15849-L-1 Upper Left Flipper
35-36 FL-11722
A-15849-L-3 Middle Left Flipper
FLASH LAMPS
37 24-8802
A-15280
Little Flipper Fishr #906
38
24-8802
*A-14265-13 Left Ramp Fishr
#906
39 24·8802
*A-14265-13 Back White Flshr
#906
40 24-8802
*A-14265·13 Back Yellow Fishr #906
41 24-8802
*A-14265-13 Back Red Fishr #906
42 24·8802
*A-14265-13 Blasting Zone Fishr #906
24-8704
A-17803
Blasting Zone Flshr #89
43 24-8802
'A-14265-13
Right Ramp Flshr#906
44 24·8704
A-17984
Jets Flshr #89
GENERAL ILLUMINATION
01
24-6549/24-8768
Plfdll nsert G.I. 1
#44f#555
02
24-6549f24-8768
Plfdllnsert G.!. 2
#44/#555
03
24-6549/24-8768
Plfdllnsert G.I. 3
#44f#555
04 24-6549
Right Plfd G.!. 4 #44
05 24-6549
Left Plfd G.!. 5 #44
• A-1426S·13 is a receptacle and skirt assembly. This
assembly is riveted to a playfield plastic or ramp. The
#906 bulb the assembly uses is sold separate.
2-49
