Switch Locations
Switch
!tmn
Number
Description
F1 SW-1A-194
Low Rt. Flipper EOS
F2 A-17316
Low Rt. Flipper Cab.
F3 SW-1A-194
Low Lt. Flipper EOS
F4 A-17316
Low Lt. Flipper Cab.
F5 SW-1A-194
Up. Lt. Flipper EOS
F6 A-17316
Up. Lt. Flipper Cab.
F7 SW·1A·194
Mid. Lt. Flipper EOS
F8 A-17316
Mid
U.
Flipper Cab.
11 5647-12693-23 Ted's Mouth
12 A-19359
Dozer Down
13 20-9663-1
Start Button
14 A-15361
Plumb Bob Tilt
15 A-19359
Dozer Up
16 5647·12693·19 Right Outlane
17 5647-12693-19 Right Inlane 2
18 5647·12693-19 Right Inlane 1
21 A-17238
Slam Tilt
22 5643-09268-00 Coin Door Closed
23 20-9663-9
Buy-l n Button
24 5643-09112-00 Always Closed
25 5647·12693-43 Red's Mouth
26 5647-12693-19 Left Outlane
27 5647-12693-19 Left Inlane
28 A-19753
Blast Zone 3-Bank
31 5647-12693-19 Skill Shot Lower
32 5647·12693·19 Skill Shot Upper
33 5647·12693-32 Right Shooter
34 A-19754
Radio 3-Bank
35 A-18060-15
Red Stand Upper Tgt.
36 A-18060-15
Red Stand Low Tgt.
37 A-19237
Hit Red
38 5647-12693-19 Right Loop Exit
41 A-18617 (LED)
Trough Jam
A-18618 (Trans)
42 A-18617 (LED)
Trough 1
A-18618 (Trans)
43 A-18617 (LED)
Trough 2
A·18618 (Trans)
44 A-18617 (LED)
Trough 3
A-18618 (Trans)
45 A-18617 (LED)
Trough 4
A-18618 (Trans)
46 5647·12693-19 Right Loop Enter
47 A-19235
Hit Bulldozer
48 A-19237
Hit Ted
51 5647-12693-24 Spinner
52 5647-12693-61 Lockup 1
53 5647·12693·61 Lockup 2
54 5647-12693-23 Lock Kickout
55 5647·12693-19 Rt. Ramp Exit Left
56 5647·12693-21 Left Ramp Exit
57 5647-12693-24 Left Ramp Enter
58 5647·12693·32 Left Shooter
61 A-19680
Left Slingshot
62 A-19680
Right Slingshot
63 B-12030-2
Left Jet Bumper
64 B-12030-2
Top Jet Bumper
65 B-12030-2
Right Jet Bumper
66
Not Used
67
Not Used
68
Not Used
71 5647-12693·24 Rt. Ramp Enter
72 5647-12693-21 Rt. Ramp Exit Center
73 5647·12693·59 Flying Rocks 5X Blast
74 5647-12693-59 Flying Rocks Radio Riot
75 5647-12693-59 Flying Rocks Ex. Ball
76 5647-12693-24 Flying Rocks Top
77 5647-12693-19 Under Blast Zone
78 5647-12693-19 Start City
Inside
Cabinet
On Coin Door
Switch
Hem Number
Description
81 A-16816-5
82 A-16816-4
83 A·16816·6
84 A-16B16-15
85 5647·12693-19
86 5647-12693-19
87
88
White Standup Tgt.
Red Standup Tgt.
Yellow Standup Tgt.
Orange Standup Tgt.
Mid. Lt. Flipper Top
Mid. Lt. Flipper Bottom
Not Used
Not Used
