Lower Playfield Parts
Item Part Number
Description
A-15849-L-1
Flipper Assembly, Lwr. Left
2 A-15849-R-4
Flipper Assembly, Lwr. Right
3
A-18753
Outhole Ball Trough Assembly
4 01-9211
Plfd. Hanger Bracket Assy. (2)
5 01-11781
Leg Support (2)
6 A-15595
7-Sw. Opto PCB
w/Bracket
7 A-19206
6-Lamp Board Assembly
8 A-17811
Kicker Arm (Slingshot) Assy.
a) B-9362-L-2
Coil
&
Bracket Assembly
9 A-19207
28-Lamp Board Assembly
10 A-19046
Loop Assembly
11 A-19047
Front Trough Assembly
12 A-15280
Single Flash Lamp Board (2)
13 B-9414
Jet Bumper Assembly
14 B-9414-5
Jet Bumper Assembly
15 B-9414-2
Jet Bumper Assembly
16 A-19129-1
Jaw Drive Assembly 'Red"
17 A-17749.1·2
Plfd. Slide Mechanism, Right
18 A·17749.1-1
Plfd. Slide Mechanism, Left
19 A·18832
Blade Drive Assembly
20 A-15340
Motor EMI PCB Assembly
21 A·19231
Rear Trough Assembly
22 A-18794
Pop-Up Assembly
a) A·19325
Bracket Pop-Up Coils
23 A·19041
Diverter Assembly, Left
24 A·19129
Jaw Drive Assembly 'Ted"
25 A·18543-2
Generic Eddy Sensor PCB (3)
26 A·19272
20·Lamp PCB Assembly
27 A-19242·1
Dual H·Drive Motor w/Bracket
28 A-15849-L4
Flipper Assembly, Upper Left
29 A·15849·L ·3
Flipper Assembly, Small
30 A-19049
Dual Diverter Assembly
a) A·19694
Link Plunger Assembly
31 A·17811
Kicker Arm (Slingshot) Assy.
a) B-9362-R-3
Coil
&
Bracket Assembly
32 A·19334
Back Panel Assembly
a) A·13941
Eject Assembly
33 A·19128
Head Assembly "Ted'
34 A-19127
Head Assembly "Red'
