Item Part No.
1 A-8476
2 B-6572
3 SW-1A-126
4 904845*
5 904845*
6 904845*
7 904704*
8 5641-09369-00
9 A-11022
10 A-11022
11 A-11022
12 A-11022
13 A-11022
14 A-11022
15 A-11022
16 A-11022
17 A-11022
18 SW-1A-124
19 SW-1A-124
20 SW-1A-124
21 SW-1A-124
22 5647-11074-00
23 5647-12001-00
24 A-7459-7
25 A-7459-7
26 A-7459-7
27 A-7459-7
28 SW-1A-124
29 SW-1A-124
30 17-1042
31 5647-12000-00
32 SW-1A-118
33 A-4834-H
34 5647-09633-00
35 SW-1A-118
36 SW-1A-118
,37 17-1012
38 17-1012
39 SW-1A-138
40 17-1067
41 5647-09633-00
42 5647-09957-00
43 SW-1A-122
44 SW-1A-122
45 A-4834-H
46 SW-1A-117
47 SW-1A-150-1
48 SW-1A-150
49-53 Not Used
54 5647 -11099-00
55-64 Not Used
SW-10A-48
Switches
Description
Plumb Bob Tilt
Ball Roll Titt
Credit Button
Right Coin Chute (* - Cainca
CenterCoinChute
pin)
Left Coin Chute
SlamTilt
High Score Reset
R StationaryTarget
o
StationaryTarget
A StationaryTarget
D StationaryTarget
K StationaryTarget
I StationaryTarget
N StationaryTarget
G StationaryTarget
S StationaryTarget
Lane 1
Lane 2
Lane 3
Lane 4
Right Ramp 1 Enter (Right)
Ramp Raise "EOS"
Top Jet Bumper
Left Jet Bumper
Right Jet Bumper
Bottom Jet Bumper
Left Outlane
RightOutiane
Drop Target
Center Ramp - Enter
Center Ramp - Right Exit
Right Ten Point
Upper Left Kicker
Right Rollunder
Left Rollunder
Left Eject
Center Eject
Ball Shooter Lane
Outhole
Right Trough
Left Trough
Left Kicker (scoring)**
Right Kicker (scoring)**
Left Ten Point
Playfield Tilt
Left Flipper EOS
Right Flipper EOS
Not Used
Right Ramp 2 Exit (Left)
Not Used
Flipper Button
u.
** [Kicker Actuating Sw: SW-1A-114; B-8734
w/RC]
