A-22966
Power Control Box Assembly
17
B!m
Part Number Description
Item Part Number Description
1
01-15126
Power Control Box
11
H-17543
Jumper, Hot Cable
2
04-12597
Switch Mounting Plate
12 H·23014
Jumper, Hot Interface
3
5642-13935-00
Rocker Switch - DPST
13 H-17545
Jumper, SWlFuse Cable
4
5733-14734-00
Fuse Holder, 5 x 20mm
14 H-17542
Jumper, Ground Cable
5
5851-13867-00
Outlet, IEC Connector
15 H·23005
3 Conductor Power Cable
237 Socket
Assembly
6
03-8712
Strain Relief Bushing
16 RM-21-Q6
#18 Vinyl Sleeving
7
5016-12978-00
Thermistor, 8A, 2.5R25
17 4408-01128-00
Nut, 8~32 KEPS
8
5822-13865-00
Terminal Strip, 3 CKT,
18 H-22991
Transformer Programming
2 Mounting
Cable
9
01-12299
Terminal Strip Insulator
19 5102-14793-00
line Filter
10 H-23015
Jumper, Neutral SWI1Fe
Note: This drawing is not to be used for the purpose of wiring the Power Control box Assembly. Refer to the
appropriate schematic diagram when attempting the wiring of this assembly.
