A-22993
Diverter Mechanism Assembly
J!!!!!
Part Number Description
1 ()4.12619
Diverter Mach Bracket
2 ()4.10911-6
%
Coil Centering Bracket
3 ()4.10911·1
%
Coil Centering Bracket
4
FL1·22241
Flipper Coil
5 03-7066-5
Coil Tubing
6 10-303
Master Spring
7 A·16636
Diverter Plunger Assembly
7a 02-4793
Diverter Plunger
7b 1
Q..389
Gate Spring
7c 20-8716-5
Roll Pin,
01/8"
x
7116"
7d 20-8712-43
E-ring,
07/16"
Shaft
8
20-8790
Nyliner Bearing
9
()4.10408
Drive Arm Assembly
10 4008-01227-0&
MS
8·32
x
3/8
PIN HD - S
11 4408-01119-01
Nut
8-32
ESNA - NTM
12 4010-01196-04
SS
10-32
x ~ SH - CP - N
Associated Parts: (Not Shown)
Part Number Description
A·22970
Diverter Paddle Assembly
2-21
