A-22989 Skip Ramp Assembly
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Part Number Description
01-15142
MainBracket
04-12615
RampBracket
04-12616.2 SkipRamp Armature Assembly
23-6420
Grommet
FL1·11753 FlipperCoil - Yellow
03-7067-6 CoilTubing
04-10911-1 Coil Centering Bracket
5647-12693-07 Sub-MiniMicro Switch
01-8600
Insulator
01-8240
PlateNut
2-56
4002-01105-08 MS
2-56
x
*
P-PH-S
4408-01119-01 Nut
8-32
ESNAlNTM
4008-01227-06 MS
8-32
x
3/8
Pin Hd SEMS
H-23019-2
2 -
Pin Cable
5076-09054-00 Diode- 1N4004 1.0A
Associated Parts: (Not Shown)
Part Number Description
A-22988
Skip RampFlapAssembly
01-15140
Flap AssemblyMounting Bracket
2-17
