50070-88
Back Box Assembly
Part Number Description
24-8809
Fluorescent Lamp
Item Part Number Description
15W.18"
1 04-12489.4 Back Box
16 04-12752
Ballast Mounting Bracket
2 A-22982
Back Boor Assembly
17 A-23155
Ballast Assembly
3 01-15131
Door Channel
18 A-23160
CPUlAC Power Cable
4 03-9992
Knob
19 H-22737-1 AC/Speaker Cable
5 A-22981
Lock
&
Plate Assembly
20 20-10583
Extension Cable
6 01-15134
Front Lock Cam
db09-1Oft
7 A-22975-50070 Marquee Assembly
21 20-10584
Extension Cable
8 04-12607.1 Speaker Grill Bracket
db25 -10ft
9
04-12606.1 Speaker Grill
10 5555-16223-00 Speaker -
4fl,
25W
Miscellaneous Parts:
11 5675-16058-02 Monitor - 19"
Item Part Number Description
12 01-15130.2 Computer Case Mounting
22 11-1464
Back Box Shipping Brace
Bracket
23 5556-15272-00 Ferrite
13 A-22724
Computer Case Assembly
*24 02-4352-2 Pivot Bushing
14 A-22980
Fluorescent Lamp
*25 4322-10228-12 CS 3/8-16 x ~ Button
Assembly
Head - Nylon Patch
*26 4700-00111-00 FW .390 x .875 x .062
*
Item not shown
2-4
