LED AND FUSE LIST
POWER DRIVER BOARD
eo
Jl00
I
o
lED2
HEALTH
0
lED17
+5v
~
~ ~~
9
••••
P
9
..
P
t§
9
Jl19
P
o
9
JJa7
bl
OlEDl
n
BLANKING
J118
8
~~ ~oQ~G
LED LIST
LED 1 Watchdog
LEO 10 +20V Flashlamps
LED 2 Health
LED 11 Solenoid Power 1
LEO 3 +18V Lamp Matrix A
LED 12 Solenoid Power 2
LED 4 +50V Lower Riaht Flipper
LED 13 Solenoid Power 3
LEOS +50V Lower Left Flipper
LEO 14 Solenoid Power 4
LED 6 +50V Upper Riaht Flipper
LED 15 +20V
LEO 7 +50V Upper Left Flipper
LED 16 +12V
LEOS +18V Lamp Matrix B
LED 17 +5V
LEO 9 +50V Solenoids
FUSE LIST
Loc.
Value
Part Number
Description
Fl00
T4.0A 250V 5371-14530-00
Solenoid Power 4
F101 T4.0A 250V 5371-14530-00
Solenoid Power 1
Fl02 T4.0A 250V 5371-14530-00
Solenoid Power 2
Fl03 T4.0A 250V 5371-14530-00
Solenoid Power 3
F104 T4.0A 250V 5371-14530-00
Lower Riaht Flipper Power
Fl05 T4.0A 250V 5371-14530-00
Lower Left Flipper Power
F106 T4.0A 250V 5371-14530-00
Upper Right Flipper Power
Fl07 T4.0A 250V 5371-14530-00
Upper Left Flipper Power
F108 T4.0A 250V 5371-14530-00
12VAC Unregulated
Fl09 T4.0A 250V 5371-14530-00
20VAC Flashlamps
Fll0
T6.3A 250V 5731-14529-00
50VAC Solenoids
F111 T5.0A 250V 5731-14046-00
18VAC Lamp Matrix A
F112 T5.0A 250V 5731-14046-00
18VAC Lamp Matrix B
LINE FUSE
Location Value
Part Number
Foreign T4.0A 1250V 5731-14530-00
Domestic T5.0A 1250V 5731-14046-00
1-29
