2 SWITCH FLIPPER BUTTON ASSEMBLY
04·12612
s'W 2
KEY
CD
Schematic
Top View
Side View
Left Side Flipper
J1-1 Black, Ground from Power Driver Board at J113-10
J1-2 Key
J1-3 Black-Blue, Flipper Button from Power Driver Board at J113·7
J1-4 Black-Gray, Feature Button from Power Driver Board at J113-9
Right Side Flipper
J1-1 Black, Ground from Power Driver Board at J113-1 0
J1-2 Key
J1-3 Black-Green, Flipper Button from Power Driver Board at J113-6
J1-4 Black-Violet, Feature Button from Power Driver Board at J113·8
