AS-2S18-21 DISPLAY DRIVER MODULE
A1: DISPLAY DRIVER MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM QTY.
DESIGNATION
PART
#
DESCRIPTION
1
1
P-2948-296
P.C. Board, M-645-392
3
7
R1,R3,R5,R7,R9,R11,R34
E-105-226
Resistor, 100K Q
4
13
R14,R16,R18,R20,R22,
E-105-227
Resistor, 300K Q
R24,R26,R35,R36,R37,
R38,R39,R40
5
6
R43,R44,R45,R46,R47,
E-105-228
Resistor, 9.1K Q
R48
6
7
R13, R15, R17, R19, R21,
E-105-229
Resistor, 1.5K Q
R23,R25
7
7
R27, R28, R29, R30, R31,
E-105-230
Resistor, 1K Q
R32,R33
8
1
R41
E-105-231
Resistor, 39K Q
9
1
R42
E-105-271
Resistor, 240K Q
10
11
2
C1,C2
E-586-65
Capacitor, .01 MFD
13
6
Q7, Q8, Q9, Q10, Q11, Q12 E-585-32
Transistor (2N5401)
14
13
Q1, Q2, Q3,
Q4,
Q5, Q6,
E-585-33
Transistor (MPS-A42)
Q13, Q14, Q15, Q16, Q17,
Q18, Q19
16
VR1
E-598-7
Zener Diode, 11OV
17
U1
E-620-38
I.C. Decoder
18
19
2
J1
E-715-34
10 Pin Wafer Pin Connector
21
1
DS1
E-680
Digital Display Panel
22
2
M-1836
Hi-Lo Screw,
W/H
23
1
P-2399
Display Mounting (Top)
24
1
P-2399-1
Display Mounting (Bottom)
26
6
R2,R4,R6,R8,R10,R12
E-105·-287
Resistor, 2.2K
n
27
6
R49,R50.R51.R52.R53.
E-105-242
Resistor, 20K
n
R54
28 As
Wr~Jumper
Req'd
NOTE: INTERCHANGEABLE WITH AS-2518-15
24
