A4: MPU MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
1
A4 (see note 1)
AS-2887-XXXX MPU Module Complete.
See page 37.
2
A4 (see note 2)
AS-2518-17
MPU Module less Program
Memory, U1-6 incl.
3-32
See Schematic
Resistors, See schematic
for value.
34
C18
E-00586-0019
Capacitor, .05 MFD, 100V
35
C16
E-00586-0081
Capacitor, .1 MFD, 100V
36
C4, C5
E-00586-0073
Capacitor, 4.5 MFD, 25V
37
C3, C6-C13, C17
E-00586-0065
Capacitor, .01 MFD, 500V
38
C14, C15, C79, C41-C67 E-00586-0067
Capacitor, 470 PFD, 1kv
39
C19-C31, C78, C33-C40
E-00586-0069
Capacitor, 390 PFD, 1kv
40
C1, C2, C68-C77
E-00586-0070
Capacitor, 820 PFD, 1kv
41
C32
E-00586-00n
Capacitor, 3000 PF, 1kv
43
Q5
E-00585-0023
Transistor PNP (MPS-3702)
44
Q1, D2
E-00585-0031
Transistor (2N3904)
47
CR44
E-00587 -0006
Diode (IN4004)
48
CR1-CR7, CR11-CR43,
E-00587-0014
Diode (IN4148)
CR45-CR48
49
CR8
E-00679
LED (Green)
50
VR1
E-00598-0008
Diode Zener (8.2V, IN9598)
52
L1, L2
E-00604-0003
Inductor, 22 Micro Hy.
53
U12
E-00620-0004
Timer (555)
54
U19
E-00620-0005
Quad 2 Input (4011)
55
U9
E-00620-0028
MPU I.C. (6800)
56
U10,U11
E-00620-0029
PIA I.C. (6820)
57
U7
E-00620-0030
RAM I.C. (6810)
59
U20
E-00620-0032
HEX Buffer I.C. (14502B)
60
U14,U18
E-00620-0033
HEX Inverter (4049B)
61
U15
E-00620-0034
Quad Memory Driver (MC3459L)
62
U16
E-00620-0035
Dual Monostable (9602)
64
U17
E-00620-0041
Quad 2 Inputs (74LOON)
65
U8
E-00620-0042
RAM (C MOS, P5101L-3)
68
BT1, BT2, BT3
E-00628-0002
Battery
70
S33
E-00658-0001
Push Button Switch
71
S1-S8, S9-S16, S17-S24,
E-00677
DIP Switch
S25-S32
73
E-00712
24 Pin Socket
74
E-00712-0001
40 Pin Socket
75
E-00712-0003
22 Pin Socket
77
J2
E-00715
15 Pin Wafer Connector
78
J4,J5
E-00715-0004
28 Pin Wafer Connector
79
J3
E-00715-0017
16 Pin Wafer Connector
80
J1
E-00715-0018
19 Pin Wafer Connector
81
J5
E-00715-0023
4 Pin Wafer Connector
NOTE 1:
When ordering, fill in dash number. For example, AS-2887-1. FREEDOM, AS-2887-2 NIGHT RIDER.
AS-2887-3 EVEL KNIEVEL
NOTE 2:
Order replacement memory chips U1-U6, by specifying game. socket and part number stamped on chip
