#1120-E POWER PLAY
8
0
RUBBER PARTS
A.
R-521·1
1 OIA
(7)
8.
R-521-2
1'/2
OIA.
(2)
o
®
0
C. R-521-4
2'/2" OIA.
(6)
D. R-406-3
FLIPPERS
(2)
0
o
0
E. R-243-
5/16'
DIA.
(2)
0
0
PANEL PARTS
1. ARCH RAIL
M-1774
©
2. RAIL POST (2)
C-907
3. RAIL POST CAP (2)
C-90B
4. BOTTOM ARCH
P-5871-56
5. SHOOTER GAUGE
P-6359-22
6. BALL REBOUND
ASE-493-6
7. BALL GATE(R)
A-1475-9
l
8. SCREENED PLASTICS
M-1330-142
8/
9. CLEAR PLASTICS
A-2890-132
10. TARGETASSEMBLY
ASE-2911-20
,-,
11. DROP TARGETASSV. (A)
ASE·2795-42
\ ,c
12. DROP TARGETASSV. (l)
ASE-2795-43
25.
.2.
~'
\
13. THUMPER CAP ASSY. (3)
A-3713·37
~
\
9
~\ \ I
21
14. GUIDE RAIL ASSY.
A-3032-3U
15. GUIDE WIRE (2)
M·121-18
~ , I
16. GUIDE WIRE (2)
M-121-30
000
0
~
,
,
"
~'
17. GUIDE WIRE
M-121·43
-
1
~-~
18. GUIDE WIRE
M·121-44
19. GUIDE WIRE (2)
M-121-46
20. GUIDE WIRE (2)
M·12153
21. GUIDE WIRE (2)
M-121-68
22. PLAY-MORE POST ASS'(,
ASE-2553-6
*
®
23. ROLLOVER WIRE (4)
ASE-2006
24. OUTHOLE WIRE
ASE-2806-21
25. MINI POST
&
RUBBER
27
0
0
0
ASSY. (3)
ASE-2836-1
cONS
26. FLIPPER & SHAFT ASSY. (2) ASE-2214-24
II
B .'
27. FLIPPER & SHAFT ASSY.
ASE-2214-25
0
28. FLIPPER & SHAFT ASSY.
ASE-2214-26
0
CONS.- CONSERVATIVE '
0
MED. ~ MEDIUM
,
LIB.
-LIBERAL
00
INDICATES MOVABLE POSTS
1
FOR SCORING ADJUSTMENTS
I
0
' ;
r ,
,. !
J- ~
I
I
9
_
.•. ,_
.....• ,:
