Page 10 - Power Play

PM".XIMliNi CREDITS:
The ~aximum credits accepted by the machine limits the number of games that can be accumulated
by COining, by winning replays or both. The maximum number of credits is selectable by means of
switches 17, ~8 and 19. Eight credits limits are available. Switch settings are listed below
MAXIMUM SWITCHES
CREDITS 19 18 17
5 OFF OFF OFF
10 OFF OFF ON
15 OFF ON OFF
20 OFF ON ON
25 ON OFF OFF
30 ON OFF ON
35 ON ON OFF
40 ON ON ON
BALLS PER GAME: # BALLS/GAME
5
3
SWITCH 16
ON
OFF
MATCH FEATURE:
When the Match Feature is ON, a random number appears in the 'Match/Ball in Play' window and the
word MATCH is illuminated. If the number matches the tens digit in a player's score, a free game is
awarded. The Match feature creates an incentive to play.
MATCH SWITCH 21
ON ON
OFF OFF
CREDIT DISPLAY: CREDITS DISPLAYED
YES
NO
SWITCH 20
ON
OFF
HIGH SCORE FEATURE:
The game is (jesigneo to award an Extra Ball or Free Game at each of the three score levels. See Front
Door Game Adjustments.
AWARD
REPLAY
EXTRA BALL
NO AWARD
SWITCH 32
ON
ON
OFF
SWITCH 31
ON
OFF
OFF
MELODY OPTION:
The game is designed to play several melodies to announce power-up, game-up, etc. The tunes are
intended to attract attention to the game and increase game usage. The tunes are controlled by
switch 8. '.
TUNES
ON
OFF
HIGH GAME TO DATE FEATURE:
The game is designed to award free games as an option if hiqh game to date is beat. Each time this
happens, the winning score becomes the new high game score to beat. This score is displayed on all 4
player score displays at the end of each game as an incentive to play. Hecornmended setting is
underlined.
SWITCH 8
ON
OFF
HIGH GAME TO DATE FEATURE
No Award
One Credit
Two Credits
Three Credits
SWITCH 7 SWITCH 6
OFF OFF
OFF ON
ON OFF
ON ON
6
