TEST/DIAGNOSTIC PROCEDU RES (Continued)
•
PRO.BlEM ANALYSIS MESSAGES (Continued)
interference by wires in the mechanism. Check complete diverter operation: (1) At game turn-
on, the diverter operates to the "InNposition. (2) Start a game, and slowly operate the Right
Ramp's 'Ramp to Car' switch (#37) twice (simulatingMulti-Ball
TN
Start) to operate the diverter to its
"Out" position.
••
Music Error. This message means that no signals are coming from the Audio Board. Check
Audio Board for presence of 1POi!..IlC~ IF@OO©~ ROMs. Also, Check thai the cable connecting
the Audio and CPU Boards is firmly seated. Tum game Off, then On, to be sure only 1 'Bing'
sounds. More than one 'Bing' or no 'Bing' indicates an Audio Board problem. Refer to the text
about the System-11B Sound Circuitry tests for more information.
••
MAINTENANCE INFORMATION
Figure 5 shows the two main lubrication points of the Shooter Lane Feeder. The shaded arrows show
the directions in which the Shooter Lane Feeder and other parts of its related assemblies can be
adjusted for proper operation. Note thai the mechanisms of the Top Left, Top Right, and Bottom Righi
Eject Hole Arm Assemblies are quite similar to the Shooter Lane Feeder; they have the same
lubrication requirements and adjustment capabilities as the
snooter
Lane Feeder...
•
•
LUB!
PCINTS
TOP VIEW
•
Figure 5. Adjustments and Lubrication Points, Shooter Lane Feeder.
•
Because of the functional design (arm-actuated via solenoid plunger operation), the pivot points of the
Left and Right Kickers ("Slingshots") aU require lubrication as a regular servicing procedure.
Mechanical adjustments are simple and somewhat similar to the Shooter Lane Feeder. These
mechanisms should also be checked for proper fit (snugly tight) where they attach to the playlield.
Lubrication to ensure proper operation also applies to the target blades of the two 3-Bank Drop
Targets. Regular maintenance is essential to a game's continuing contribution to the operator's
earnings.
