GAME ADJUSTMENT PROCEDURE
•
Adjustment
Items 01 through 70
The coin door must be open to access the Game AdjustmenUDiagnoslic switches.
All readings and
setting changes require operation of these coin door switches. Some setting changes utilize the Credit
button; some also use the flipper button(s).
Additional text describing the game adjustment items
follows this procedure; the value of the Factory Setting for each Game Adjustment item
is
in the
preceding
1?l@1l.0@~ IF@~©~ Game
Adjustment
Table.
•
1 .
Use AUTO-UP and press ADVANCE. The Id 00 display initially appears. Press ADVANCE until
the Player 3 display indicates Ad 01.
If the factory setting has not changed, the upper Player
Score display indicates AUTO REPLAY, and the lower display shows 10%, indicating a 10% replay
percentage.
(The game program adjusts itself automatically, as discussed in the following text
concerning the 'details' about Adjustment Item 01.)
2. To reach a higher item number (in the lower display), use AUTO-UP and press ADVANCE.
To
return to a previous item number, use MANUAL-DOWN and press ADVANCE.
3. With the desired Game Adjustment Item number showing in the lower display, increase the setting
value {or select another option} shown in the lower display by using AUTO-UP and pressing the
Credit button. Repeat this step for each item, until all changes to the factory settings for the Game
Adjustment Items have been made. The preceding Game Adjustment Table consolidates the
Factory Settings into one grouping.
•
(The same procedure can be used for Audit Items. To zero Au 01 - 04 (concerning the coin
chutes and the total coins), the operator can proceed to item 68, Clear Coins, and press the
Credit button to obtain the YES option. The operator then presses the ADVANCE button and
notes the "DONE" display, which verifies that the entry values for items 01 through 04 of the Audit
Items are now reset to zero.}
For example, the operator may desire to change the degree of game play difficulty from the
Factory Setting (equivalent to the Install Medium (Ad 64] difficulty, along with a number of other
automatically installed settings, as shown in the right column of the Game Adjustment Table) to
another difficulty more suitable for the players at a particular game site. Four other 'automatic' play
difficulty settings (Ad 62 - Ad 66) are available, each of which, if selected, installs all the
adjustments listed for that difficulty in the Game Adjustment Setting Comparison Table. which
precedes the 'details' text.
4. To proceed rapidly through the entire adjustments series, press
and hold
ADVANCE, until Ad
70 shows in the lower display. From item 70, you can: (A) return to the Game-Over Mode; or (8)
restore factory settings and zero audit (bookkeeping) totals Perform either of the following, as
desired:
•
A. To reach Game-Over Mode, use AUTO-UP and press ADVANCE once.
1P©l1.0©1E:
I;::©[;l©~ now
goes to the Game-Oyer Mode .
•
B. To restore the Factory Settings for Game Adjustment Items (as listed in the Game Adjustments
Table), zero all audit (bookkeeping) totals,
and
return to Game-Qver Mode, use AUTQ-UP or
MANUAL-DOWN to display Ad 70 in the lower display. Press the Credit button to display the
YES option in the lower display. Using AUTO-UP, press ADVANCE once.
f?©1.0©1:
lj::@rf.ltl'_2
now zeroes ALL Audit Item totals and changes ALL Game Adjustment Items back to those
originally selected as Factory Settings. It then shows the operator a message ("FACTORY
SETTING") that this has occurred. (A problem in the Memory Protection circuit or closing the
coin door will cause the message "ADJUST FAILURE" to appear.) Press ADVANCE once more
to return to the Game-Over Mode.
