Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside the
cabinet. The plumb bob weight is among the parts in the cash box; the operator should
install the weight and adjust this tilt mechanism for proper operation, after completion of the
desired playfield pitch angle setting.
•
PINBALL GAME ASSEMBLY INSTRUCTIONS
(Continued)
8.
Place a level or an inclinometer on the playfield surface. Adjust the leg levellers for proper playfield
level (side-to-side)
saa
playfield pitch angle (incline) of approximately 6-7 degrees.
NOTE: It is
•
recommended that these measurements be made ON the playlield, not the cabinet nor the playfield
cover glass. Tighten the nut on each leg leveller shaft to maintain this setting, as shown in Figure 3.
9.
Move the game into the desired location; recheck the level and pitch angle of the playfield.
10. Verify that the
required number
of balls are installed in the game.
(~@[1.0©~ ~@!Rl©~:
2 baus)
11. Clean and reinstall the playfield cover glass, reversing the procedure of step 7. Prepare the game
for player operation ..
GAME OPERATION
( WA RN ING )
After assembly and installation at its site location, this game must be plugged into a properly
grounded oullet to prevent shock hazard, and to assure proper game operation. DO NOT use a
'cheater' plug to deleat the ground pin on the line cord. DO NOT cut off the ground pin.
POWERING UP. Perform the following 'power up' routine upon completion of the assembly and
installation procedure, as well as at the beginning of each period of game operation. Initially, it will confirm
•
that the game is in proper operating condition; later, it will aid the operator via its messages.
Procedure.
With the coin door closed, plug the game in, and switch it ON, using the On-Off switch. In
normal operation, the player 1 score display initially shows 00. Then, the game goes into the Attract Mode
(playfield and backbox lamps flashing, sounds being heard, etc., il the operator does not change the
Factory Setting).
Open the coin door and press the AUTO-UP/MANUAL-DOWN switch to MANUAL-DOWN.
Press the
ADVANCE button to begin the game test routine. Return to AUTO-UP and perform the.e..o1i.r.e.t st routine
to verify that the game is operating satisfactorily. Succesful completion of the tests shows that the game is
ready to begin earning your investment return.
After the game has been on location for a period of time, the test routine may be preceded by messages
concerning game problems.
The text entitled 'Problem Analysis Messages'
at the end of the
Text/Diagnostic Procedures contains more details concerning messages displayed at each game turn-on.
•
ATTRACT MODE".
Playfield and backbox lamps blink.
The player score displays exhibit a series of
messages informing the player concerning:
A. Recent highest scores':
B.
A "custom message"
("BE TOP COP ... PLAY ... POLICE FORCE,,)*;
C. The score to achieve to obtain a Replay award';
These (or similar) displays reappear occasionally, accompanied by sounds and music, until a player initiates
•
game play by inserting a coin or, when credits are available, pressing the Credit button.
-
