DISPLA Y GAME STATUS - TEST 04
When this test is entered,
the match digits will display 04
to indicate test 04. This test displays on Player I display
the current game status for the 18 functions that can be
changed according to section 3 in this manual and for the
5 bookkeeping totals which can be accessed as described
in Section 4. Changes to the game status CANNOT be
made at this time! To make changes the diagnostics must
be in the Game Status Change section of the diagnostics
as previously explained.
When this test is entered, if the AUTO/MANUAL switch
is in the AUTO position the test will sequentially display
the game status data values on the Player I display and the
function number on the credits display and continue cyc-
ling until the ADVANCE pushbutton is pressed. If the
ADV ANCE pushbutton is pressed once, the diagnostics
will end and the game will go to the GAME OVER mode.
If the ADVANCE pushbutton is pressed once and then
after a I second pause pressed a second time, the diag-
nostics will start all over again with the CPU Self Tests
and then go to Game Status Change section of the diag-
nostics.
If the AUTO/MANUAL switch is in the MANUAL posi-
tion when the test is entered,
the credit display will show
01, Player I display the value of whatever is function 01,
and will remain that way until the ADVANCE pushbut-
ton is pressed, at which time the value for function 02 will
be display on Player I display and 02 will display in the
credit display. Each time the ADVANCE pushbutton is
pressed, the credit display will increment by 1, until 23 is
reached then it will return to 01. This will continue until
the AUTO/MANUAL switch is returned to the AUTO
20
position and the ADVANCE pushbutton pressed once or
twice as described above. Note that for test 4 functioe
numbers 6 and 8 thru 14, values above 09 will not be dis-
played correctly.
Refer to Table I for an explanation of
the values read out during this test.
AUTO CYCLE MODE
As an aid in diagnosing intermittent
problems or as a
means to let the machine cycle itself through portions of
the diagnostics,
provision was made for the AUTO
CYCLE MODE. This mode will sequence through the
digit display test, go to test 0 I and flash the lamps 128
times then go to test 02 and energize each solenoid then
digit test, test 0 I, etc. This can be allowed to run
indefinitely or until the ADVANCE pushbutton is
pressed to regain control of the diagnostics.
To enter the AUTO CYCLE MODE:
I. Turn game OFF then turn game ON.
2. Press the diagnostic pushbutton on the CPU Board to
enter diagnostics.
3. Set the data and function switches as follows:
DA TA SWITCH (TOP SWITCH) - Turn
all
switches
OFF. FUNCTION SWITCH (BOTTOM SWITCH) -
Turn
all
sitches OFF then turn ON only switch I.
4. Press ENTER pushbutton on CPU Board. The two
LEOs will blink to accept the data.
5. Place the AUTO/MANUAL switch to AUTO.
6. Press ADVANCE pushbutton ONCE.
The AUTO
CYCLE MODE will begin and continue until th~
ADV ANCE pushbutton is pushed again to regain"?
manual control of the diagnostics or the machine is
turned OFF.
