504
TYPICAL
*
*
LOWER
BACKBOX
UPPER
LOWER
UPPER
*
SEE INSERT BOARD WIRING DIAGRAM FOR
CONNECTIONS FOR BACKBOX LAMPS.
) GENERAL
ILLUM I NATION
ONLY CONNECTIONS TO LAMPS IN LOWER
PLAYFIELD ARE ROUTED THRU 8P5/8J5.
-----
24
Playfield Lamp Wiring Diagram
_j.,____.
1#
Bulb
No.
Function
01
Same Player Shoots Again (Back box)
-
~
02
Left Magnet, Bottom Arrow
03
2X Scoring
04
"A"
05
Slaves Tomb Extra Ball When Lit
06
"0"
07
"l" Bonus
08
''9'' Bonus
09
Ball in Play
10
Left Magnet. 2+ Arrow
II
Hidden Tomb Collect Bonus
12
"0"
13
Upper Eject Hole Arrow
14
"H"
15
"2" Bonus
16
"10" Bonus
17
Tilt
18
Left Magnet 4+ Arrow
19
Lower Center 3-Bank
20
"H"
21
Lower Eject Hole Arrow
22
Extra Ball When Lit Hidden Tomb
23
"3" Bonus
24
"20" Bonus
25
Game Over
26
Right Magnet Bottom Arrow
27
Lower Right S-Bank
28
Upper Bull's-Eye Target
29
"pOI
(Back box)
30
Slaves Tomb General Illumination
31
"4" Bonus
32
"30" Bonus
33
Match
34
Right Magnet 2+ Arrow
35
"P" (Playfield)
36
Upper Left 3-Bank Bottom Arrow
37
"H"
38
Captive Ball General Illumination
39
"5" Bonus
40
"40" Bonus
41
High Score to Date
42
Right Magnet 4+ Arrow
43
"H"
44
Upper Left 3-Bank Center Arrow
45
"A"
46
Upper Center 3-Bank Left Arrow
47
"6" Bonus
48
2X
49
Bonus Ball Timer
50
Left? Lane
51
"A"
52
Upper Left 3-BankTop Arrow
53
"R"
54
Upper Center 3-Bank Center Arrow
55
"7" Bonus
56
3X
57
Same Player Shoots Again (Playfield)
58
Right? Lane
59
"R"
60
Lower Bull's-Eye Target
61
"A"
62
Upper Center 3-Bank Right Arrow
63
"S" Bonus
64
5X
