XI. PARTS LIST
#1167 ..E PARAGON
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
,
E-122-12S
Bulbs, #44 ,
E-12S-22
Fuse, 1 Amp, 3 A6 Slow Blow (Playfield Solenoid Protection)
E-133-44
ASSEMBLY COILS
~
Coin Lockout
, ,
, .. ,
FO-36- 7000
Flipper (4)
, .. " .. ,',
AQ-2S-S00/
34-4S00
Knocker
AR-26-1200
Outhole Kicker
AN-26-1200
Thumper-Bumper (4)
AN-26-1200
Sling-Shot (2)
AN-26-1200
Drop Target Reset (2)
,
NO-26-1900
Saucer (3)
AO-27-1300
PLAYFIELD PARTS
See Figure II
MODULES
Lamp Driver AS
AS-2518-23
Display Driver A1 (5 Used)
AS-2S18-21
Solenoid Driver/Voltage Regulator A3
AS-2518-22
MPU A4
AS-2962-8
Transformer & Rectifier A2
AS-2877-1
Rectifier Board (Part of A2)
.-
AS-2518-18
Sound
AS-2888-4
REPAIRS PROCEDURES! AIDS
Module & Component Replacement
F.O.560-1
AID (Assistance in Diagostics)
Kit, used with FO.560-1
KIT #485-1
MODULE COMPONENTS
SEE MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each Kit contains an assortment of the most needed electronic parts for use in Module
repair.)
Kit #490-For
Rectifier Board (Part of A2)
Kit #503-For
MPU Board A4 (Less Memory U1-U6)
Kit #492-For
Solenoid Driver/Voltage Regulator A3
Kit #493-For
Display Driver A1
Kit #494-For
Lamp Driver AS
Kit #S18-For Sound A8
20
