#1167-E PARAGON
RUBBER PARTS
A. R-243
B.
R-521
C. R-521-1
D. R-521-2
E.
R-521-3
F.
R-521-4
G. R-521-5
H.
R-521-6
I. R-406-3
5/6" DIA.. (4)
'14~
DIA.
1"
DIA.
(5)
lW'DIA.
2" DIA.
(4)
2111" DIA.
3" DIA.
3W'
DIA.
FLIPPERS (3)
PANEL TOP PARTS
1. Arch Rail
M·1774
2.
Rail Post
C·907
3. Rail Post Cap
C-908
4.
Bottom Arch
P·5871-67
5. Shooter Gauge
P-6359-33
6.
Ball Gate Assembly
(R)
A·1475-13
1.
Ball Gate Assembly
(Ll
A·1475-12
8.
Ball Gate
&
Wire
Assembly ASE·2250-11
9.
8all Gate &: Wire Assembly ASE·2250-59
10. Ball Gate
&
Wire Assembly ASE·2250·25
11.
Ball Gate
&
Wire Assembly ASE-2250-18
12. Ball Gate
&.
Wire Assembly ASE·2250-60
13. Screened Plastic Set
M·1330-161
14. Spinner Gale Assembly (L) ASE·2250·51
15. Thumper Cap Assembly
(4)
A-3713-50
16.
Drop Target Assembly
(3)
ASE·279S-30
17. In-Line Drop Target Assy.
(4)
ASE·2993
18.
Outhole Wire
ASE·2806·21
19.
Rollover
Wire
ASE·2806
20. Ball Guide Wire
M·121-53
21. Target Assembly
ASE·2911·3
22. Ball Guide Wire (4)
M·121·46
23. Flipper
&
Shaft Assembly (3)AS~-2214·24
24.
Flipper & Shaft Assembly (1)ASE·2214-25
25. Ball Guide Wire
M·121·18
26. Ball Guide Wire
M·121-47
27. Ball Guide Wire
M-121·30
28.
Ball Guide Wire
M-121·83
29. Rollover Bulton (4)
C·90Q
30. MIni-Post Assembly (7)
AS-2836·1
CONS.--CONSERVATIVE
MED. -MEDIUM
LIB. -LIBERAL
INDICATESMOVABLEPOSTS
FOR SCORINGADJUSTMENTS
