A-22010 Floating Ramp Coil
&
Bracket Assembly
N
l
Item Part Number
Description
~
U
1 04-10965.1
Floating Ramp Bracket
2 L.E-23-1300
Coil Sub Assembly Thermal
~
,
3 04-10911-4
5/8
Coil Centering Bracket
~
4 03-7066-5
Coil Tubing
5
01-14731
Adjusting plate
~
,
6 4408-01119-01 Nut 8-32 ESNA
,
7
4008-01168-08 Mach. Screw: 8-32 x
Y2"
~r
~
8 4700-00011-00 Flat Washer:
11/64
x
7116
x 16ga.
,
9
20-8790-5
Nyliner Bearing
Associated Assemblies:
10 02-5323
Mod CS 10-32 x
2-1/2"
11 10-523
Spring - Floating Ramp
12 02-5322
Adjusting Collar
13 4410-01132-01 Nut 10-32 ESNA
14 A-22200
Floating Ramp Assembly
a) 04-10964.1
Floating Ramp
b) 01-14732
Floating Ramp Flap
c) 07-6688-17N Rivet:
1/8
x
3/16"
Nickel
d) 4008-01003-06 Mach. Screw: 8-32 x
3/8"
e) 02-5321
Post 8-32
f) 23-6824
Bumper Sleeve
g) 4700-00011-00 Flat Washer: 11/64 x
7/16
x 16ga.
h) 4008-01041-06 Mach. Screw: 8-32 x 3/S"
m
<.
:
~r'"
"",J
..........•.....•
,
'1 '
I
'
::~'
, I
,
,
'
I I
,
'
,
'
: :
4
::
U'
,
,
I ,
l_~::~
2-26
