A-22205-2 Jet Coil
&
Bracket Assembly
,
I
I
I
I
I
I
I
I
I
1.......
I
"
I
"
I
" I
'~
Item Part Number
Description
1
04·10888
Bracket & Stop Assembly
2
01·1747
Coil Retaining Bracket
3
01·5492
Armature Link, Steel
4
01·5493
Armature Link, Bakeline
5
02·3406·1
Coil Plunger
6
10-326
Armature Spring
7
AE·26·1200
Coil Assembly
8
4006·01017·04
Mach. Screw, 6-32 x 1/4"
9
03·7066
Coil Tubing
Associated Parts:
(Not Shown)
10
8·12030-2
Leaf Switch Assembly
a)
A·l6443
Switch & Diode Assembly
b)
01·1168
Switch Mounting Bracket
c)
01·3670
Switch Plate
d)
03-7395
Switch Actuator
e)
4005·01003·12
Mach. Screw, 5-40 x 3/4"
f)
4405·01117·00
Nut 5-40 Hex.
2-21
