A-18753
Ball Trough Assembly Complete
Item Part Number
Description
Item Part Number
Description
1 A-16809-2
Ball Trough Welded Assy.
11 4008-01017-05
Mach. Screw, 8-32 x
5/16"
2
01-11587
Ball Trough Front
12 4408-01119-00
Nut 8-32 ESN
3 A-6306-2
Bell Armature Assembly
13
4008-01017-06
Mach. Screw, 8-32 x
3/8"
4
AE-26-1500
Coil Assembly
14
23-6702
Bumper Plug
5
01-8-508-T
Solenoid Assembly
15 A-18617
Trough IRED LED PCB Assembly
6
03-7067-5
Coil Tubing
16
A-18618
Trough IRED Transistor PCB Assy.
7
10-135
Spring
17 4006-01003-10
Mach. Screw, 6-32 x
5/8"
SEMS
8
23-6420
Rubber Grommet
18
23-6626
Rubber Grommet
9
03-8523
Insulator
19
4700-00004-00
Flat Washer,
9/64
x
7/16
x
21
gao
10
01-11586
Coil Mounting Bracket
20
02-4975
Bushing
2-18
