A-15849-R
Flipper Assembly
~REF
Item Part Number
Description
Item Part Number
Description
1
B-13104-R
Flipper Base Assembly, Right
·18
A-15848-R
Crank Link Assembly, Right
2
SW-1A-194
Switch Assembly
a)
A-17050-R
Flipper Crank Assembly, Right
3 4701-00002-00
Lock Washer #6 Split
1.
01-11764-R
Flipper Crank, Right
4
4105-01019-10
Sh. Metal Screw, #5 x
5/S"
2.
4700-00107-01
Mod-Crank Washer
5 4008-01079-05
Mach. Screw, S-32 x 5/16"
3.
RM-23-06
H.S. Tubing W
6
4701-00003-00
Lock Washer #8 Split
4.
4010-01066-20
Mach. Screw, 10-32 x 1-1/4"
7
01-9375
Switch Mounting Bracket
5.
4410-01127-00 Nut, 1
0-32
Hex.
8
20-6516
Speednut, Tinnerman
6.
4700-00107-00
FW: 13/64 x 5/S x 12ga.
9 4010-01066-06
Cap Screw, 10-32 x 3/S"
7.
4701-00004-00
Lockwasher #10 Split
10 4701-00004-00
Lock Washer #10 Split
8.
01-9376
Spring Retainer Bracket
11
A-12390
Flipper Stop Assembly
b)
A-15847
Flipper Link Assembly
12
FL-11630
Flipper Coil
c)
02-4676
Link Spacer Bushing
13
01-7695-1
Solenoid Bracket
d)
4010-01086-14
Cap Screw, 10-32 x 7/8"
14 4006-01017-04
Mach. Screw, 6-32 x 1/4"
e)
4700-00023-00
Flat Washer,
5/8 x 13/64 x 16ga.
15 10-364
Spring
f)
4701-00004-00
Lock Washer #10 Split
16 4006-01005-06
Mach. Screw, 6-32 x 3/8"
g)
4410-01132-00
Nut 10-32 ESN
17 4406-01117-00
Nut 6-32 Hex.
19
23-6577
Bumper Plug, 5/8"
20
03-7568
Flipper Bushing
21
03-7066-5
Coil Tubing
Associated Parts: (Not Shown)
23-6519-4
Flipper Ring
20-10110-6
Flipper Bat w/Shaft
• See page 2-15 for assembly detail drawing.
2-16
